L989F D0600-2906001088 Electric equipment

1 4041002410 管夹LGB169-A12*10 Clamp Y 13

2 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 13

3 4130001710 温度传感器WDG1371B Temperature sensor Y 1

4 29370022522 变速箱线束 Wiring harness Y 1

5 4011001275 螺栓GB16674.1-M6*16flZnyc-8.8-480 Screw Y 5

6 4014000535 螺钉GB818-M5*12flZnyc-4.8-480 Screw Y 3

7 4015000431 垫圈GB97.1-5flZnyc-300HV-480 Washer Y 3

8 4130001124 变速控制器LGTC-2 Control unit Y 1

9 4130002409 Steer column switch 408.993 Switch N 1

10 4014000523 螺钉GB818-M5*16flZnyc-4.8-480 Screw Y 2

11 29370022871 过渡支架 Bracket Y 1

12 4190001839 扎丝LG13-ZS4*160 Cable tie Y 4

13 4041002412 管夹LGB169-A20*10 Clamp Y 1

14 4130001119 压力开关YK213B/D Pressure switch Y 1

15 29360023341 操纵集成标识 Decal Y 1

16 4043002075 护套LGB313-B6*50*80 Rubber sleeve Y 1

17 4130002613 操纵集成控制器 Control unit Y 1

18 4130002515 操纵手柄MS-04P9/FNR-R1P9 Control handle Y 1

19 4013000046 螺母GB6172.1-M12EpZn-05 Nut Y 1
