L989F A0310-2903004119 Assembly compound

1 29030010811 管夹 Clamp Y 1

2 29030041381 补水管 Hose Y 1

3 4017000010 喉箍JB8870-d20 Clamp Y 4

4 29030022061 节流器 Nipple Y 1

5 4090000307 胶管HG2491-10*600 Hose Y 1

6 4190001839 扎丝LG13-ZS4*160 Cable tie Y 4

7 29030025321 溢流管 Hose Y 1

8 4011001299 螺栓GB16674.1-M10*25flZnyc-8.8-480 Screw Y 2

9 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 2

10 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2

11 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 3

12 11219198 副水箱 Expansion tank Y 1

13 29030025501 副水箱支架 Bracket Y 1

14 4090000304 胶管HG2491-10*1300 Hose Y 1

15 4041002411 管夹LGB169-A15*10 Clamp Y 2

16 4011001358 螺栓GB5783-M10*30flZnyc-10.9-480 Screw Y 3

17 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 3

18 4017000009 喉箍JB8870-d50 Clamp Y 2
