L978F 转向器总成 Steering gear system I2000-2920001221

1 4120001870 接头GEO08LMOMDA3C Nipple Y 2

2 4190000181 接头EW08LOMDA3C Elbow nipple Y 3

3 4041001292 软管LGB124-003130 Hose assembly Y 1

4 4120002993 接头GE20S11/16UNOMDCF Nipple Y 1

5 29200012221 三通接头EL20S-M14*1.5 Three-way nipple Y 1

6 4120001854 测试接头VKA3/08LA3C Testing nipple Y 1

7 4120002992 胶管F3811CCA201810-1660 Hose assembly Y 1

8 4120002987 接头GE30S15/8UNOMDCF Nipple Y 1

9 4120002006 接头EW30SOMDCF Nipple Y 1

10 4011000262 螺栓GB5782-M12*110EpZn-8.8 Bolt Y 2

11 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 2

12 4013000011 螺母GB6170-M12EpZn-8 Nut Y 2

13 4120002730 优先阀VLH-240 Priority valve Y 1

14 29200012161 转向柱部装总成 Steering column N 1

15 4041000187 直接头LGB120-02622 Nipple Y 4

16 4041000771 O形圈LGB168-11924 O-ring Y 4

17 29200008981 转向器出油钢管 Pipe Y 4

18 4030000501 O形圈GB3452.1-15.0*1.80G O-ring Y 4

19 4120003023 接头GE08L7/16UNFOMD Nipple Y 2

20 4120000456 法兰总成M1M1HK-16 Flange half Y 1

21 4120002986 胶管F731C919301616-880 Hose assembly Y 1

22 4041002834 软管LGB128-003170 Hose assembly Y 1

23 4120002717 转向器BZZ8-1182 Control valve Y 1

24 4011000560 螺栓GB16674-M12*25EpZn-8.8 Bolt Y 2

25 29200008861 固定板 Anchor plate Y 1
