L959F 传动轴总成 Propeller shaft E0800-2908001023

1 4011001363 螺栓GB5786-M14*1.5*40flZnyc-10.9-480 Bolt Y 4

2 4015000435 垫圈GB97.1-14flZnyc-300HV-480 Washer Y 4

3 29080010241 L959F传动轴总成 Propeller shaft N 1

4 4011001398 螺栓GB5785-M14*1.5*55flZnyc-10.9-480 Screw Y 8

5 4013000399 螺母GB889.2-M14*1.5flZnyc-10-480 Nut Y 8

6 4011001395 螺栓GB5785-M16*1.5*65flZnyc-10.9-480 Screw Y 4

7 4013000402 螺母GB889.2-M16*1.5flZnyc-10-480 Nut Y 4

8 4015000436 垫圈GB97.1-16flZnyc-300HV-480 Washer Y 8

9 4011001293 螺栓GB5785-M12*1.25*50flZnyc-8.8-480 Screw Y 4

10 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 4

11 4110002923 传动轴C52*625 Propeller shaft Y 1

12 4110002185 中间支撑 Propeller shaft Y 1

13 4110003960 传动轴PC52*938.5 Propeller shaft Y 1

14 29080000051 后传动轴 Propeller shaft Y 1

15 4110002066002 突缘叉1491.707-2201062-J Link yoke Y 3

16 4110002515002 卡簧1491.707-2201063 Lock ring Y 16

17 4110002923001 十字轴总成0125-52133-T Spider Y 4

18 4110002086003 油杯M6 JB/T7940.1-1995 Grease cup N 2

19 4110003723001 突缘叉1491.707-2201062-B Link yoke N 1

20 4110001858005 六角头螺栓1/2\”-20UNF-2B*58-10.9 Screw Y 8

21 4120001054234 垫圈GB93-87 12 Washer Y 8

22 2908000753001 万向节十字轴总成G5-7126 Spider Y 2
