L959F 输出端4474.102.285 (450202) Hub reduction E0722-4110000047
L959F 输出端4474.102.285 (450202) Hub reduction E0722-4110000047
1 7200001828 右轮边支承轴4474207022 Shaft Y 1
2 7200001829 带槽螺母0737503046 Nut Y 1
3 7200001830 右轮边支承轴4474207041 Shaft Y 1
4 7200001829 带槽螺母0737503046 Nut Y 1
5 4110000047011 密封环 0734.309.412 190*220*14,5/18 Sealing ring Y 2
6 4110000047112 滚子轴承140000*210000*45000 Needle bearing Y 2
7 7200001835 防尘罩4474306090 Dust cover Y 2
8 4110000047113 滚子轴承150000*225000*48000 Needle bearing Y 2
9 4110000047014 轮毂 4474.306.215 AP-411 GJS-400-15 Housing Y 2
10 7200001838 O型圈0634313487 O-ring Y 4
11 7200001839 内齿圈支撑架4474206031 Ring gear carrier Y 2
12 7200001832 封塞0631405030 Stuff Y 4
13 7200001841 环A=（23.65）0730161565 Spacer ring Y 2
14 4110000047015 环 0730.161.564 A=23,60 Ring Y 2
15 4110000047016 环 0730.161.563 A=23,55 Ring Y 2
16 4110000047017 环 0730.161.562 A=23,50 Ring Y 2
17 4110000047018 环 0730.161.561 A=23,45 Ring Y 2
18 4110000047019 环 0730.161.560 A=23,40 Ring Y 2
19 4110000047020 环 0730.161.559 A=23,35 Ring Y 2
20 4110000047021 环 0730.161.558 A=23,30 Ring Y 2
21 4110000047022 环 0730.161.557 A=23,25 Ring Y 2
22 4110000047023 环 0730.161.556 A=23,20 Ring Y 2
23 4110000047024 环 0730.161.555 A=23,15 Ring Y 2
24 4110000047025 环 0730.161.554 A=23,10 Ring Y 2
25 4110000047114 环A=22.0 0730.162.034 Ring Y 2
26 4110000047027 环 0730.162.033 A=22,05 Ring Y 2
27 4110000047028 环 0730.162.032 A=22,10 Ring Y 2
28 4110000047029 环 0730.162.031 A=22,15 Ring Y 2
29 4110000047030 环 0730.162.030 A=22,20 Ring Y 2
30 4110000047031 环 0730.162.029 A=22,25 Ring Y 2
31 4110000047032 环 0730.162.028 A=22,30 Ring Y 2
32 4110000047033 环 0730.162.027 A=22,35 Ring Y 2
33 4110000047034 环 0730.162.026 A=22,40 Ring Y 2
34 4110000047035 环 0730.162.025 A=22,45 Ring Y 2
35 4110000047036 环 0730.162.024 A=22,50 Ring Y 2
36 4110000047037 环 0730.162.023 A=22,55 Ring Y 2
37 4110000047038 环 0730.162.022 A=22,60 Ring Y 2
38 4110000047039 环 0730.162.021 A=22,65 Ring Y 2
39 4110000047040 环 0730.162.020 A=22,70 Ring Y 2
40 4110000047041 环 0730.162.019 A=22,75 Ring Y 2
41 4110000047042 环 0730.161.553 A=23,05 Ring Y 2
42 4110000047043 环 0730.161.552 A=23,00 Ring Y 2
43 4110000047044 环 0730.161.551 A=22,95 Ring Y 2
44 4110000047045 环 0730.161.550 A=22,90 Ring Y 2
45 4110000047046 环 0730.161.549 A=22,85 Ring Y 2
46 4110000047047 环 0730.161.548 A=22,80 Ring Y 2
47 7200001842 止动垫圈4474307097 Thrust washer Y 2
48 7200001843 活塞4474307082 Cylinder piston Y 2
49 4110000045029 弹性挡圈 4462.305.083 IN 4462 305 022 Retaining ring Y 2
50 4110000045030 弹性挡圈 4462.305.014 IN 4462 305 022 Retaining ring Y 2
51 4110000047003 弹簧0732 020 088 Spring Y 16
52 4110000045031 带槽环 0734.317.100 VINA 247,5-1 Retaining ring Y 4
53 7200001848 后置密封圈0734317196 Sealing ring Y 2
54 7200001849 后置密封圈0734317197 Sealing ring Y 2
55 7200001850 活塞导环0501312493 Piston ring Y 2
56 7200001851 活塞导环0501312494 Piston ring Y 2
57 4110000047123 外摩擦片A=4.0 4474304049 Friction disc Y 10
58 7200001853 外摩擦片（A=5.0）4474304048 Friction disc Y 10
59 4110000047001 内摩擦片0501 208 915 Friction disc Y 8
60 7200001855 端垫4474305011 Washer Y 2
61 4110000047052 太阳轮轴 4474.306.213 Z=17 Shaft Y 2
62 4110000047053 摩擦片支架 4474.306.188 Z=34 ZF7B C Bracket Y 2
63 7200001860 环 4474307139 Spacer ring Y 2
64 7200001973 卡环0630502190 Lock ring Y 2
65 4110000047054 行星架 4474.306.211 34CRMO4 Planet carrier Y 2
66 7200001863 螺塞 4475 280 015 Plug Y 2
67 7200001864 “O”型圈0634306523 O-ring Y 1
68 7200001865 O型圈 0634.304.100 310*2,5 O-ring Y 2
69 7200000923 行星齿轮4464306161（ZF桥） Planetary gear Y 8
70 7200000924 轴承0735455314（ZF桥） Bearing Y 8
71 4110000047056 弹性挡圈 0630.501.219 54*1,8 Retaining ring Y 8
72 7200001868 止动垫圈 s=5.00730106148 Thrust washer Y 2
73 4110000045036 止动垫圈 0730.106.592 S=6,0 Thrust washer Y 2
74 4110000045037 止动垫圈 0730.106.975 S=6,3 Thrust washer Y 2
75 4110000045038 止动垫圈 0730.106.976 S=6,5 Thrust washer Y 2
76 4110000045039 止动垫圈0730.107.103 S=3,5 Thrust washer Y 2
77 4110000045040 止动垫圈 0730.107.102 S=3,3 Thrust washer Y 2
78 4110000045041 止动垫圈0730.107.101 S=3,1 Thrust washer Y 2
79 4110000045042 止动垫圈 0730.107.100 S=2,9 Thrust washer Y 2
80 4110000047115 止动垫圈S=2.7 0730.107.099 Thrust washer Y 2
81 4110000045044 止动垫圈0730.107.582 S=3,7 Thrust washer Y 2
82 4110000045045 止动垫圈 0730.107.583 S=3,9 Thrust washer Y 2
83 4110000045046 止动垫圈 0730.107.584 S=4,1 Thrust washer Y 2
84 4110000045047 止动垫圈0730.108.167 S=4,8 Thrust washer N 2
85 4110000045048 止动垫圈 0730.108.168 S=5,2 Thrust washer N 2
86 4110000045049 止动垫圈0730.108.169 S=5,4 Thrust washer N 2
87 4110000045050 止动垫圈0730.108.170 S=5,6 Thrust washer N 2
88 4110000045051 止动垫圈0730.107.513 S=7,5 Thrust washer N 2
89 4110000045052 止动垫圈0730.108.304 S=1,9 Thrust washer Y 2
90 4110000045053 止动垫圈0730.108.848 S=1,7 Thrust washer N 2
91 4110000045054 止动垫圈 0730.108.849 S=1,8 Thrust washer N 2
92 4110000045055 止动垫圈 0730.111.728 A=6,8 Thrust washer N 2
93 4110000045056 止动垫圈 0730.111.729 A=7,0 Thrust washer N 2
94 7200001869 六角螺钉0636021072 Screw Y 64
95 4110000047116 螺塞4475.280.150 Plug N 2
96 4110000045002 O型圈 0634.304.731 38 * 2,2 O-ring Y 1
97 4110000045058 螺钉 0750.108.075 Screw Y 2
98 7200001864 “O”型圈0634306523 O-ring Y 2
99 7200001877 排气阀0501205154 Valve Y 2
