L948F 离合器 4644 152 556 Clutch C0549-4110001742

1 7200001575 轴4644352062 Shaft Y 1

2 4110000076380 O形圈 0634 313 536 49*3 O-ring Y 1

3 4110000076050 搭扣密封环 0734 401 106 Sealing ring Y 3

4 7200001536 螺柱(M8*18)0636610014 Stud Y 2

5 7200001675 六角螺母(M8)0637006018 Nut Y 2

6 4110001742014 调整垫圈 0730 003 501-505,157-164 Shim Y 1

7 4110000367099 承磨垫0730 150 759 Thrust washer Y 1

8 4110000367100 止动垫片4644 303 529 Thrust washer Y 1

9 4110001742013 齿轮 4644 351 093 Gear Y 1

10 4110000367118 止动垫圈4644 308 265 Thrust washer Y 2

11 4110000367101 承磨垫0730 150 773 Thrust washer Y 1

12 4110000367102 滚子组35,2*55,2*37 0750 119 100 Roller Y 1

13 4110000367103 垫圈4644 308 266 Washer Y 1

14 4110000076199 止动片4644351094 Extension bar Y 1

15 4110000076191 止动片4642308555 Extension bar Y 1

16 4110000076247 承磨垫 0730 150 779 DUP Washer Y 1

17 4110001742015 齿轮 4644 252 106 Gear N 1

18 4110000367127 滚柱轴承 K45*75*32,2/24,4 0750 115 211 Bearing Y 1

19 4110000367110 挡圈 0501 308 830 Retaining ring Y 3
