LG952N 4120006922 齿轮泵(370142) Gear pump

1 4120000171044 挡圈41060100200 Retaining ring Y 1
2 4120000171046 挡圈41060100100 Retaining ring Y 1
3 4120000171045 旋转轴唇形密封圈43020200100 Sealing ring Y 2
4 4120006922004 前盖21020200510 Cover N 1
5 4120000171048 环形密封圈 44020100300 Sealing ring Y 2
6 4120000171049 滚针轴承42010100100 Needle bearing Y 4
7 4120000171050 定位套21020900110 Spacer sleeve Y 4
8 4120000171051 耳形挡片21020800110 Retaining ring Y 2
9 4120000171052 耳形密封垫21020700110 Sealing washer Y 2
10 4120000171053 侧板21020600110 Side board Y 2
11 4120006922001 主动齿轮轴21020112210 Drive shaft Y 1
12 4120006922005 从动齿轮轴21020412010 Shaft Y 1
13 4120006922002 泵体21020312010 Pump body N 1
14 4120001060003 后盖21020500110 Cover Y 1
15 4120006922003 螺钉44010101980 Screw Y 4
16 4120001715017 螺钉41010101780 Screw Y 4
17 4120000171043 弹簧垫圈41050200600 Spring washer Y 4
18 4120001715018 弹簧垫圈41050200500 Spring washer Y 4
19 4120006922009 密封件包 Sealing ring kit N 1
