LG952N 4120006611 动臂油缸(3713CH) Lifting cylinder

1 4120006611001 缸筒总成24A138700 Cylinder tube Y 1
2 4120006628002 活塞杆总成24A113870 Piston rod Y 1
3 4120006611002 缸盖24C101110 Cover Y 1
4 4120006000005 衬套24S290401 9040 Bushing Y 1
5 4120005980008 钢丝挡圈-孔用24C090220 Retaining ring Y 1
6 4120005999004 密封件-缓冲24H009004 Sealing ring N 1
7 4120005999005 密封件-活塞杆24F209003 Sealing ring N 1
8 4120005999006 挡圈-U形圈24E009025 Retaining ring N 1
9 4120005999007 密封件-防尘24D209001 Sealing ring N 1
10 4120005980009 钢丝挡圈-孔用24C090240 Retaining ring Y 1
11 4120006611003 O形圈24K11500A O-ring N 1
12 4120006611004 挡圈-O形圈24M11600D O-ring N 1
13 4120006611005 O形圈24K315761 O-ring N 1
14 4120006611006 活塞24C102080 Piston Y 1
15 4120006611007 密封件-活塞24P216002 Sealing ring N 1
16 4120005999013 O形圈24K10900A O-ring N 1
17 4120005999014 挡圈-O形圈24M30950A O-ring N 1
18 4120006611008 支承环24G216051 Sealing ring N 2
19 4120005980011 活塞背母24C103050 Nut Y 1
20 4090000168 钢球GB308-5-GCr6 Ball Y 1
21 4120005685008 螺钉-内六角凹端紧定24T908161 M8*16L Screw Y 1
22 4120006628006 轴套24C116150 Bushing Y 1
23 4120006611009 销边防尘24R308540 Sealing ring N 2
24 4120006611010 螺钉-内六角圆柱头24T516755 Screw Y 12
25 4120005685012 固定座24C003020 M16 Anchorage Y 1
26 4120006611011 密封件包24A103320S Sealing ring kit Y 1
