LG952N 4120002314 多路阀(43329) Control valve assembly

1 4016000035 开口销GB91-4*20EpZn-Q235A Split pin Y 2

2 4120002279101 圆肩销DF-32-01 Pin Y 2

3 4015000026 垫圈GB93-12-65Mn Spring washer Y 2

4 4120002314105 动臂阀杆GDF-32Ⅲ-03c1 Valve rod N 1

5 4120002279107 压板GDF-32-04 Plate Y 2

6 4120002432407 防尘圈CK28 Sealing ring Y 2

7 4120002432405 垫圈GDF-32-02 Washer Y 2

8 4120001052010 O形圈27.7×3.55G O-ring N 4

9 4030000610 O形圈GB3452.1-11.8*1.80G O-ring Y 1

10 4120005199025 测压口堵头GDF-32-18 Plug Y 1

11 4030000011 O形圈GB1235-20*2.4 O-ring Y 1

12 4120001054222 螺塞D32-3 Plug Y 1

13 4030000757 O形圈GB3452.1-31.5*3.55G O-ring Y 2

14 4120005199007 阀盖GDF-32-05 Valve cover N 2

15 4120005199008 单向阀弹簧GDF-32-07 Valve spring N 2

16 4120005199009 单向阀GDF-32-08 Direction valve Y 2

17 4030000760 O形圈GB1235-50*3.1 O-ring Y 1

18 4030000013 O形圈GB1235-32*3.1 O-ring Y 3

19 4120005199028 螺塞DF-32-20A Plug Y 1

20 4120003809004 阀体YGDF-32-01B1 Valve body Y 1

21 4120002279114 垫板GDF-32-09A Plate Y 2

22 4120002279116 弹簧座GDF-32-10a Spring seat N 1

23 4120002432420 弹簧407428 Spring N 1

24 4090000162 钢球GB308-11.112-GCr15 Ball Y 2

25 4120002432427 密封垫GDF-32-17 Sealing Y 2

26 4015000036 垫圈GB93-8-65Mn Spring washer Y 8

27 4011000708 螺栓GB21-M8×20 Screw Y 4

28 4120002432428 端盖GDF-32-14B Valve cover Y 1

29 4120002279121 端盖橡胶塞GDF-32-20 Rubber plug Y 1

30 4120002279119 端盖橡胶塞GDF-32-19 Rubber plug Y 1

31 4120002432429 端盖GDF-32-12B Valve cover Y 1

32 4011001194 螺栓GB21-M8*15EpZn-8.8 Screw Y 4

33 4120002279118 弹簧压座GDF-32-11 Spring seat Y 2

34 4120002432421 弹簧座GDF-32-15 Spring seat N 1

35 4120002432425 回位弹簧GDF-32-16 Spring Y 1

36 4120002314010 安全阀XDY32G02-00A-18 Valve Y 1

37 4120002059003 高压过载阀D32A.1-00b-20 Valve Y 1

38 4120002314106 过载阀阀体ZL50106C-01A Valve Y 1

39 4015000025 垫圈GB93-10-65Mn Spring washer Y 8

40 4011000050 螺栓GB5782-M10*60EpZn-8.8 Bolt Y 8

41 4120002432432 转斗阀杆GDF-32-06e Valve rod Y 1

42 4120002432431 过载补油阀阀体 ZL50106C1-01 Valve Y 1

43 4030000981 O形圈GB1235-28*3.1 O-ring Y 2

44 4120002038161 低压过载阀XDYB20G01-00E-12 Valve Y 1

45 4014000578 P-螺钉GB67-M6*10EpZn-4.8 Screw Y 8
