LG944MSK 2920000806 转向器总成 Steering gear system

1 4041000516 软管LGB164-010150 Hose assembly Y 1

2 29200008561 转向器出油钢管A Pipe Y 1

3 4030000289 O形圈GB3452.1-16.0*1.80G O-ring Y 2

4 29200004031 转向器出油钢管B Hose assembly Y 1

5 4041000564 直接头LGB120-02620 Nipple Y 4

6 4041000783 O形圈LGB168-11724 O-ring Y 4

7 4041000734 软管LGB128-003080 Hose assembly Y 1

8 4041001047 组合接头LGB143-01406 Nipple Y 1

9 4041000131 直接头LGB120-01412 Nipple Y 3

10 4041000784 O形圈LGB168-10924 O-ring Y 3

11 29200008251 转向器进油胶管 Hose assembly Y 1

12 4041000187 直接头LGB120-02622 Nipple Y 1

13 4041000771 O形圈LGB168-11924 O-ring Y 1

14 29200008461 固定板 Anchor plate Y 1

15 4011000560 螺栓GB16674-M12*25EpZn-8.8 Bolt Y 2

16 4011000302 螺栓GB16674-M8*75EpZn-8.8 Bolt Y 2

17 4120000709 优先阀VLE-150 Priority valve Y 1

18 4041000188 直接头LGB120-03028 Nipple Y 1

19 4041000779 O形圈LGB168-12331 O-ring Y 1

20 4041000514 软管LGB165-003121 Hose assembly Y 1

21 4041000774 螺塞LGB135-01422 Plug Y 1

22 4041000767 O形圈LGB168-11124 O-ring Y 1

23 4030000530 O形圈GB3452.1-6.00*1.80G O-ring Y 1
