LFT18 2912003194 Hydraulic control system

1 29120030611 先导阀总成PCL402-4MBM3H3B-C部装 Control lever N 1

2 4041000767 O形圈LGB168-11124 O-ring Y 11

3 4041000604 直接头LGB120-01614 Nipple Y 3

4 4041000048 软管LGB128-004206 Hose Y 1

5 4041000133 直接头LGB120-01414 Nipple Y 5

6 4041001047 组合接头LGB143-01406 Nipple Y 3

7 4030000530 O形圈GB3452.1-6.00*1.80G O-ring Y 3

8 4041002512 软管LGB124-003218 Hose assembly Y 1

9 4190000204 三通接头ET08LOMDA3C Three-way nipple Y 1

10 29120019621 先导管支架 Bracket Y 1

11 4011001238 螺栓GB5783-M10*20flZnyc-8.8-480 Screw Y 6

12 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 6

13 29120029541 滤油器固定板 Plate Y 1

14 4120001954 滤油器PLF-C30*10 Hydraulic fluid filter Y 1

15 4011001302 螺栓GB16674.1-M10*16flZnyc-8.8-480 Screw Y 2

16 4041001023 组合接头LGB143-01608 Nipple Y 6

17 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 6

18 4120005063 压力选择阀SF8-D Valve Y 1

19 4011001298 螺栓GB16674.1-M10*55flZnyc-8.8-480 Screw Y 2

20 29120014931 垫圈 Washer Y 2

21 29120007661 接头 Nipple Y 1

22 4041001552 软管LGB125-005168 Hose assembly Y 1

23 29120007651 接头 Nipple Y 1

24 4120001100 三通接头EL10LOMDA3C Three-way nipple Y 1

25 4041002715 软管LGB124-004175 Hose assembly Y 1

26 4041001537 软管LGB125-004030 Hose assembly Y 1

27 4041002417 管夹LGB169-B20*12.5 Clamp Y 1

28 4041000774 螺塞LGB135-01422 Plug Y 1

29 4041000768 O形圈LGB168-11524 O-ring Y 2

30 4041002774 直接头LGB120-01818*80 Nipple Y 1

31 4030000490 O形圈GB3452.1-10.0*1.80G O-ring Y 1

32 4041001063 组合接头LGB143-01810 Nipple Y 1

33 4041000766 直接头LGB120-01818 Nipple Y 1

34 4041002773 直接头LGB120-01614*80 Nipple Y 1

35 4011001303 螺栓GB16674.1-M8*90flZnyc-8.8-480 Screw Y 4

36 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 4

37 29120016351 固定板 Anchor plate Y 2

38 29120016741 管夹 Clamp Y 4

39 29120020071 弯板 Plate Y 1

40 4041001554 软管LGB125-003070 Hose assembly Y 1

41 4041002514 软管LGB164-005130 Hose assembly Y 1

42 4041001858 软管LGB124-003210 Hose Y 2

43 4041001362 软管LGB124-003280 Hose assembly Y 1

44 4041000602 软管LGB124-004170 Hose Y 1

45 4030000276 O形圈GB3452.1-32.5*2.65G O-ring Y 2

46 29120015081 接头 Nipple Y 2

47 4041002724 软管LGB164-004210 Hose assembly Y 1

48 4120001954001 滤芯（先导滤清器滤芯)PLFX-30X10 Filter insert Y 1
