L978F 转向油缸(3713CH) Steering cylinder assembly I2110-4120002674

1 4120002674016 缸筒总成24A131310 Cylinder tube Y 1

2 4120002674017 活塞杆总成24A110850 Piston rod Y 1

3 4120002674018 缸盖24A170310 Cover Y 1

4 4120003878009 斯特封24F906301 Sealing ring N 1

5 4120002674019 密封件-活塞杆24F406313 Sealing ring N 1

6 4120003878011 支承环24G306331 Sealing ring N 2

7 4120002674020 密封件-防尘24DA06302 Sealing ring N 1

8 4120000602123 O形圈 24K309511 O-ring N 1

9 4120000602124 挡圈-O形圈 24M31002A O-ring Y 1

10 4120006603013 O形圈24K310001 O-ring N 1

11 4120002674021 活塞24A180310 Piston Y 1

12 4120000602125 密封件-活塞24P410014 Piston N 1

13 4120005026026 纳污环 92*100*6 24N010002 Sealing ring N 2

14 4120003878019 O形圈24K306311 O-ring N 1

15 4090000168 钢球GB308-5-GCr6 Ball Y 1

16 4120004831016 螺钉-内六角圆柱头24T506121 Screw Y 1

17 4120000602127 支承环 24G210031 Sealing ring Y 1

18 4120003878021 关节轴承24U105001 Spherical plain bearing N 1

19 4120006441005 弹性挡圈-孔用-A型24T007501 Retaining ring N 1

20 4120002674022 密封件包24A100630S Sealing ring kit Y 1
