L978F 右台架总成 Platform assembiy M3440-2934004725

1 29340047341 右后扶手 Hand rail Y 1

2 29340047261 右台架 Platform Y 1

3 29340021351 橡胶板 Mudflap Y 1

4 29340021421 压板 Plate Y 1

5 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 4

6 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 4

7 29340047331 右梯 Ladder Y 1

8 4011001243 螺栓GB5783-M12*35flZnyc-8.8-480 Screw Y 4

9 4015000427 垫圈GB96.1-12flZnyc-300HV-480 Washer Y 7

10 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 7

11 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 9

12 4011001241 螺栓GB5783-M12*25flZnyc-8.8-480 Screw Y 1

13 29340047381 右前扶手 Hand rail Y 1

14 4043001970 防松套LGB331-12*24*16flZnyc-45 Attaching sleeve Y 18

15 4011001251 螺栓GB5783-M12*45flZnyc-8.8-480 Screw Y 7

16 29340019581 右支架 Bracket Y 1

17 4011001252 螺栓GB5783-M12*60flZnyc-8.8-480 Bolt Y 2

18 4011001508 螺栓GB5783-M12*40flZnyc-8.8-480 Bolt Y 9
