L978F 变速操纵总成 Shift mechanism system D0600-2906000950

1 4041002410 管夹LGB169-A12*10 Clamp Y 13

2 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 13

3 4130001710 温度传感器WDG1371B Temperature sensor Y 1

4 29370022522 变速箱线束 Wiring harness Y 1

5 4011001343 螺栓GB16674.1-M6*12flZnyc-8.8-480 Screw Y 1

6 4041002412 管夹LGB169-A20*10 Clamp Y 1

7 4130001119 压力开关YK213B/D Pressure switch Y 1

8 4130001711 变速操纵线束 Wiring harness Y 1

9 4130001124 变速控制器LGTC-2 Control unit Y 1

10 4014000535 螺钉GB818-M5*12flZnyc-4.8-480 Screw Y 3

11 4015000431 垫圈GB97.1-5flZnyc-300HV-480 Washer Y 3

12 4130002409 Steer column switch 408.993 Switch N 1

13 4014000523 螺钉GB818-M5*16flZnyc-4.8-480 Screw Y 2

14 29370022871 过渡支架 Bracket Y 1
