L978F 举升缸总成 Lift cylinder F1300-2913002470

1 4120002672 动臂油缸HSGF-180*100*896-1428 Lifting cylinder Y 2

2 29130013181 左动臂缸小腔钢管 Pipe Y 1

3 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 8

4 4011001298 螺栓GB16674.1-M10*55flZnyc-8.8-480 Screw Y 8

5 4011001288 螺栓GB16674.1-M10*50flZnyc-8.8-480 Screw Y 8

6 29130013031 阀至举升联小腔钢管 Pipe Y 1

7 4120003012 法兰总成FHS65CF Flange half Y 2

8 29130012971 阀至举升联大腔钢管 Pipe Y 1

9 29130013151 左动臂缸大腔钢管 Pipe Y 1

10 29130013211 左支架 Bracket Y 1

11 4011001375 螺栓GB16674.1-M12*30flZnyc-8.8-480 Bolt Y 8

12 4041001017 U形螺栓LGB159-13040 U-bolt Y 14

13 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 28

14 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 32

15 4120002971 胶管F3726A6A161616-1620 Hose assembly Y 4

16 4120001099 法兰总成M2M2HK-16 Flange half Y 8

17 29130010821 管夹 Clamp Y 4

18 4041000869 缓冲套LGB123-0740 Rubber sleeve Y 4

19 4011001296 螺栓GB16674.1-M8*20flZnyc-8.8-480 Screw Y 2

20 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 2

21 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

22 29130013111 举升联右小腔钢管 Pipe Y 1

23 4041000043 分体法兰LGB117-310490 Flange half Y 4

24 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 16

25 29130013091 举升联右大腔钢管 Pipe Y 1

26 29130013251 右支架 Bracket Y 1

27 29130013171 右动臂缸大腔钢管 Pipe Y 1

28 29130013201 右动臂缸小腔钢管 Pipe Y 1

29 4041000774 螺塞LGB135-01422 Plug Y 3

30 4041000767 O形圈LGB168-11124 O-ring Y 3

31 29130013141 固定板 Anchor plate Y 2
32 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 4
33 29130013051 举升联左大腔钢管 Pipe Y 1
34 29130013071 举升联左小腔钢管 Pipe Y 1
35 4041001018 底板LGB160-3040 Bracket Y 4
36 29130012991 举升缸后端衬套 Sleeve Y 2
37 4043000057 防尘圈LGB307-95 Sealing ring Y 4
