LG968N 3/4档总成 Shaft and clutch assembly C0520-2905001627

1 29050016111 齿轮 R43 Gear Y 1

2 4015000241 挡圈GB893.1-110-65Mn Retaining ring Y 1

3 4021000154 轴承6212/C3 Bearing Y 1

4 4015000155 挡圈GB894.1-60-65Mn Retaining ring Y 1

5 29050016121 密封垫 Gasket Y 1

6 4019000025 铆钉GB827-3*10-BL2 Rivet Y 2

7 29050016181 板 Plate Y 1

8 29050016131 轴承套 Bearing bushing Y 1

9 4015000288 垫圈GB1230-12EpZn-45 Washer Y 2

10 4011000795 螺栓GB5786-M12*1.25*30EpZn-8.8 Screw Y 2

11 29050016141 透气管 Tube Y 1

12 4011000106 螺栓GB5783-M8*25EpZn-8.8 Bolt Y 8

13 4030000827 O形圈GB3452.1-103*3.55G-FPM O-ring Y 1

14 29050016151 盖 Cover Y 1

15 29050015471 垫圈8 Washer Y 8
