LG968N 转向泵(370142 ) Steering pump assembly I1901-4120005048

1 4120000171044 挡圈41060100200 Retaining ring Y 1

2 4120000171045 旋转轴唇形密封圈43020200100 Sealing ring Y 2

3 4120005048003 前盖21040200410 Cover N 1

4 4120000171046 挡圈41060100100 Retaining ring Y 1

5 4120000171048 环形密封圈 44020100300 Sealing ring Y 1

6 4120000171049 滚针轴承42010100100 Needle bearing Y 8

7 4120000171050 定位套21020900110 Spacer sleeve Y 8

8 4120000171051 耳形挡片21020800110 Retaining ring Y 4

9 4120000171052 耳形密封垫21020700110 Sealing washer Y 4

10 4120000171053 侧板21020600110 Side board Y 4

11 4120005082001 主动齿轮轴21132210110 Drive shaft Y 1

12 4120005048005 从动齿轮轴21020410010 Shaft Y 1

13 4120005048004 泵体21061710010 Pump body N 1

14 4120000171057 环形密封圈 44020100600 Sealing ring Y 2

15 4120005048006 中间体21131200110 Centering block N 1

16 4120005048010 主动齿轮轴21111108010 Drive shaft Y 1

17 4120005048007 从动齿轮轴21020408010 Shaft Y 1

18 4120005048009 泵体21131808010 Pump body N 1

19 4120005048013 环形密封圈 44020100400 Sealing ring N 1

20 4120005048014 O型圈43010101500 O-ring N 1

21 4120005048008 后盖21030508110 Cover N 1

22 4120005048001 螺钉44010104580 Screw Y 4

23 4120000171043 弹簧垫圈41050200600 Spring washer Y 4

24 4120001715018 弹簧垫圈41050200500 Spring washer Y 3

25 4120001715017 螺钉41010101780 Screw Y 3

26 4120002432105 弹垫8-G97.1 41050200300 Spring washer Y 2

27 4120005048012 螺钉41010100980 Screw Y 2

28 4120005082002 密封件包 Sealing ring kit Y 1
