LG968N 后车架及附件 Rear frame system K2700-2927001070

1 4015000162 垫圈GB97.1-10EpZn-300HV Washer Y 26

2 4011000082 螺栓GB5783-M10*25EpZn-8.8 Bolt Y 10

3 29270010731 支架 Bracket Y 1

4 4043000374 垫片LGB303-45*80*1 Shim Y 4

5 4014000024 螺钉GB818-M6*10EpZn-4.8 Screw Y 8

6 29250000311 管夹 Clamp Y 4

7 4015000035 垫圈GB93-6-65Mn Spring washer Y 8

8 4030000065 油杯JB7940.1-M10*1 Lubricating nipple Y 6

9 29270009101 走线胶套 Rubber sleeve Y 2

10 4011000474 螺栓GB16674-M10*25EpZn-8.8 Bolt Y 2

11 29270010071 上铰接销 Pin Y 1

12 29270010081 防尘圈 Sealing ring Y 2

13 4015000270 挡圈GB893.1-120-65Mn Retaining ring Y 2

14 4021000243 关节轴承GB9163-GE80ES Spherical plain bearing Y 1

15 29270009421 塑料塞 Plastic plug Y 2

16 29270010881 下铰接销 Pin Y 1

17 29270010131 套 Bushing Y 2

18 4030000260 旋转轴唇形密封圈GB9877.1-B100*125*12 Sealing ring Y 2

19 4011000983 螺栓GB16674.1-M12*120EpZn-8.8 Screw Y 8

20 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 12

21 29270010181 盘 Flange Y 1

22 29270010161 垫片 Shim Y 1

23 29270010151 垫片 Shim Y 2

24 29270010171 垫片 Shim Y 1

25 4021000244 滚动轴承GB297-33216 Roller bearing Y 2

26 29270010141 盘 Flange Y 1

27 4013000214 螺母GB6177.1-M12EpZn-10 Nut Y 8

28 29270010891 套 Grommet Y 1

29 29270010241 垫片 Shim Y 1

30 29270010251 垫片 Shim Y 1

31 29270010231 垫片 Shim Y 1
32 29270010221 垫片 Shim Y 1
33 29270010261 盘 Flange Y 1
34 4011000269 螺栓GB5783-M1650EpZn-8.8 Screw Y 4 35 4015000181 垫圈GB97.1-16EpZn-300HV Washer Y 8 36 4011000069 螺栓GB5782-M1690EpZn-8.8 Bolt Y 4
37 29270010781 左踏脚 Foot step Y 1
38 29270010821 右踏脚 Foot step Y 1
39 29270011191 润滑油管 Pipe Y 1
40 29270011201 润滑油管 Pipe Y 1
41 29250000301 垫片 Shim Y 8
42 29250000291 通油螺栓 Bolt Y 4
43 29270010271 转向销轴 Pin Y 2
44 4011000197 螺栓GB5783-M1225EpZn-8.8 Bolt Y 12 45 29270012871 右盖板 Plate Y 1 46 29270010421 转向润滑油管 Pipe Y 2 47 4190001829 缓冲器 Absorber Y 2 48 4011000514 螺栓GB5783-M1045EpZn-8.8 Bolt Y 8
49 4013000007 螺母GB6170-M10EpZn-8 Nut Y 8
50 29270012231 左盖板 Cover plate Y 1
