LG968N 后主传动总成 Rear final drive assembly E0912-2909000841

1 29090008231 螺母 Nut Y 1

2 29090008241 垫圈 Washer Y 1

3 29090008221 法兰 Connection flange Y 1

4 29070011641 防尘罩 Dust cover Y 1

5 4030000592 密封圈 GB9877.1-FB85*140*12F Sealing ring Y 1

6 4021000139 滚动轴承GB297-31312 Roller bearing Y 1

7 29070008901 调整垫片 Shim Y 1

8 29070008911 调整垫片 Shim Y 1

9 29070012041 隔套 Spacer sleeve Y 1

10 29070012101 隔套 Spacer sleeve Y 1

11 29070012131 隔套 Spacer sleeve Y 1

12 29090008401 托架 Center housing N 1

13 4021000141 滚动轴承GB297-33117 Roller bearing Y 2

14 29070011601 调整螺母 Nut Y 2

15 29070011621 轴承座 Bearing seat N 2

16 29070011121 垫圈 Washer Y 4

17 4011000217 螺栓GB5782-M20*110EpZn-10.9 Bolt Y 4

18 29070011581 止推垫片 Thrust washer Y 2

19 4011000597 螺栓GB5786-M10*1*20EpZn-8.8 Bolt Y 4

20 29070011441 调整垫片 Shim Y 1

21 29070011451 调整垫片 Shim Y 1

22 29070011461 调整垫片 Shim Y 1

23 29070011471 调整垫片 Shim Y 1

24 29070011481 调整垫片 Shim Y 1

25 29070011491 调整垫片 Shim N 1

26 4021000140 滚动轴承GB297-31315 Roller bearing Y 1

27 29090008271 主动螺旋伞齿轮 Crown wheel N 1

28 29070011571 锥齿轮垫片 Thrust washer Y 4

29 29070011551 锥齿轮 Differential pinion Y 4

30 29070011561 一字轴 Shaft Y 2

31 29090008281 从动螺旋伞齿轮 Crown wheel N 1

32 29070011541 半轴齿轮 Differential side gear Y 2

33 29070011531 垫片 Shim Y 2

34 29070011521 垫片 Shim Y 2

35 29070011511 差速器右壳 Differential housing N 1

36 29070009511 垫圈 Washer Y 32

37 4011000731 螺栓GB5786-M16*1.5*50-10.9 Screw Y 20

38 29070011631 差速器左壳 Differential housing N 1

39 4011000801 螺栓GB5782-M16*95-10.9 Screw Y 12

40 21909002421 后主从动螺旋伞齿轮 Gear kit N 1

41 21909002371 差速器左右壳 Housing Y 1

42 21909006461 锥齿半齿总成 Gear kit Y 1

43 29070019591 差速器总成 Differential spider Y 1

44 29090008211 输入法兰 Flange Y 1

45 29090008391 托架总成 Center housing Y 1

46 29070012051 隔套 Spacer sleeve Y 1

47 29070012061 隔套 Spacer sleeve Y 1

48 29070012071 隔套 Spacer sleeve Y 1

49 29070012081 隔套 Spacer sleeve Y 1

50 29070012091 隔套 Spacer sleeve Y 1

51 29070012111 隔套 Spacer sleeve Y 1

52 29070012121 隔套 Spacer sleeve Y 1
