LG968N 变矩器总成 Torque converter assembly C0520-2905001563

1 4041000775 O形圈LGB168-21124 O-ring Y 5

2 29050014411 螺塞 Plug Y 5

3 4011000106 螺栓GB5783-M8*25EpZn-8.8 Bolt Y 8

4 29050015471 垫圈8 Washer Y 16

5 29050013191 端盖 End plate Y 1

6 29050013181 密封垫 Gasket Y 1

7 4041000777 螺塞LGB135-02227 Plug Y 1

8 4041001265 O型圈LGB168-21924 O-ring Y 1

9 4016000243 销GB119.2-10*18-B Pin Y 4

10 4016000224 销GB119.2-20h6*45-B Pin Y 1

11 29050013651 安全阀 Safety valve Y 1

12 29050013371 销轴 Pin Y 1

13 4011000107 螺栓GB5783-M8*30EpZn-8.8 Bolt Y 8

14 29050013091 盖板总成 Cover plate Y 1

15 29050013081 密封垫 Gasket Y 1

16 29050012971 变矩器壳体 Converter housing Y 1

17 29050013781 垫片 Gasket Y 1

18 29050013601 定位销 Locating pin Y 1

19 29050013611 垫片 Shim Y 5

20 4011000777 螺栓GB5783-M10*30-8.8 Screw Y 5

21 29050015581 导轮座总成 Seat N 1

22 29050014521 取力器过渡齿轮总成 Gear Y 2

23 29050014501 变矩器润滑系统 Lubricating system N 1
