L959F Connector C0540-4110002936

1 4110000042107 连接壳体4644 330 385 Intermediate housing Y 1

2 7200001454 六角螺钉(M10*50)0636010460 Screw Y 14

3 4110000042124 张紧销钉0631 329 100 Pin Y 2

4 7200001456 张紧销钉0631329072 Pin Y 2

5 4110002936001 盖板4657330075 Cover Y 1

6 4110002936002 螺栓0736101583 Screw Y 4

7 4110001742004 O形圈 0634 306 287 O-ring Y 1

8 7200001458 膜片4644330239 Diaphragm Y 2

9 4110002230007 六角头螺钉0636 102 411 Screw Y 4

10 7200001460 垫圈4644330228 Washer Y 1

11 4110002230008 垫圈0630 100 284 Washer Y 4

12 7200001462 垫圈4166330123 Washer Y 1

13 7200001463 O形圈(25×3)0634313260 O-ring Y 1

14 7200001464 卡环(30×1.2)0630502015 Lock ring Y 1

15 7200001465 盖4644330242 Cover Y 1

16 7200001466 六角螺钉(M10x12)0636015169 Screw Y 4

17 4110000042125 中间环4644 330 222 Flange Y 1

18 7200001468 螺钉(M12x30)0636900127 Screw Y 12
