L959F 输出端 4474.102.288（450202） Hub reduction E0930-4110000045

1 4110000045006 毂架4474.205.037 Seat Y 2
2 7200001945 带槽螺母 0737.503.053 IN 0737 503 052 Nut Y 1
3 7200001946 封塞0631405029 Plug Y 8
4 4110000045007 密封环0734.309.422 Sealing ring Y 2
5 7200001948 滚子轴承0750117200 Needle bearing Y 2
6 4110000045008 滚柱轴承0750 120 106 Roller bearing Y 2
7 7200001950 轮毂 4474.305.230 IN 4474 305 228 Housing Y 2
8 7200001951 O型圈0634313369 O-ring Y 2
9 7200001952 O型圈0634313049 O-ring Y 2
10 7200001953 内齿圈支承架4474 205 080 Ring gear carrier Y 2
11 7200001955 垫圈S=4.700730162297 Washer Y 2
12 4110000045009 垫圈0730.162.298 Washer Y 2
13 4110000045010 垫圈0730.162.299 Washer Y 2
14 4110000045011 垫圈0730.162.300 Washer Y 2
15 4110000045012 垫圈0730.162.301 Washer Y 2
16 4110000045013 垫圈0730.162.302 Washer Y 2
17 4110000045014 垫圈0730.162.303 Washer Y 2
18 4110000045015 垫圈0730.162.304 Washer Y 2
19 4110000045016 垫圈0730.162.305 Washer Y 2
20 4110000045017 垫圈0730.162.306 Washer Y 2
21 4110000045018 垫圈0730.162.307 Washer Y 2
22 4110000045019 垫圈0730.162.308 Washer Y 2
23 4110000045020 垫圈0730.162.309 Washer Y 2
24 4110000045021 垫圈0730.162.310 Washer Y 2
25 4110000045022 垫圈0730.162.311 Washer Y 2
26 4110000045023 垫圈0730.162.779 Washer Y 2
27 4110000045024 垫圈0730.162.780 Washer Y 2
28 4110000045025 垫圈0730.162.781 Washer Y 2
29 4110000045026 垫圈0730.162.782 Washer Y 2
30 4110000045027 垫圈0730.162.783 Washer Y 2

31 4110000045028 垫圈4474.305.190 Washer Y 2
32 7200001957 锁紧环4474306022 Lock ring Y 2
33 7200001958 活塞4474307085 Piston Y 2
34 7200001844 卡环4462305083 Ring Y 2
35 7200001960 卡环4462305014 E-circlip Y 2
36 7200001961 拉簧0732020084 Spring Y 16
37 7200001962 U型密封圈0734317100 Sealing ring Y 4
38 7200001848 后置密封圈0734317196 Sealing ring Y 2
39 7200001849 后置密封圈0734317197 Sealing ring Y 2
40 7200001850 活塞导环0501312493 Piston ring Y 2
41 7200001851 活塞导环0501312494 Piston ring Y 2
42 7200001852 外摩擦片（A=4.0）4474304049 Friction disc Y 8
43 4110000045032 外摩擦片 4474.304.048 A=4,5 Friction disc Y 8
44 4110000047001 内摩擦片0501 208 915 Friction disc Y 6
45 7200001855 端垫4474305011 Washer Y 2
46 4110000045033 太阳轮轴 4474 305 376 Shaft Y 2
47 7200001972 摩擦片支架4474305316 Bracket Y 2
48 7200001974 环4474305332 Spacer Y 2
49 7200001973 卡环0630502190 Lock ring Y 2
50 4110000045073 行星齿轮架 4474.305.379 Planet carrier Y 2
51 7200001863 螺塞 4475 280 015 Plug Y 2
52 7200001864 “O”型圈0634306523 O-ring Y 1
53 7200001865 O型圈 0634.304.100 3102,5 O-ring Y 2 54 4110000045074 行星齿轮Z=35 4464.301.318 Planet gear Y 8 55 4110000045076 固位环502 0630.501.035 Retaining ring Y 8
56 7200001868 止动垫圈 s=5.00730106148 Thrust washer Y 2
57 4110000045036 止动垫圈 0730.106.592 S=6,0 Thrust washer Y 2
58 4110000045037 止动垫圈 0730.106.975 S=6,3 Thrust washer Y 2
59 4110000045038 止动垫圈 0730.106.976 S=6,5 Thrust washer Y 2
60 4110000045039 止动垫圈0730.107.103 S=3,5 Thrust washer Y 2

61 4110000045040 止动垫圈 0730.107.102 S=3,3 Thrust washer Y 2
62 4110000045041 止动垫圈0730.107.101 S=3,1 Thrust washer Y 2
63 4110000045042 止动垫圈 0730.107.100 S=2,9 Thrust washer Y 2
64 4110000045043 止动垫圈 0730.107.99 S=2,7 Thrust washer Y 2
65 4110000045044 止动垫圈0730.107.582 S=3,7 Thrust washer Y 2
66 4110000045045 止动垫圈 0730.107.583 S=3,9 Thrust washer Y 2
67 4110000045046 止动垫圈 0730.107.584 S=4,1 Thrust washer Y 2
68 4110000045047 止动垫圈0730.108.167 S=4,8 Thrust washer N 2
69 4110000045048 止动垫圈 0730.108.168 S=5,2 Thrust washer N 2
70 4110000045049 止动垫圈0730.108.169 S=5,4 Thrust washer N 2
71 4110000045050 止动垫圈0730.108.170 S=5,6 Thrust washer N 2
72 4110000045051 止动垫圈0730.107.513 S=7,5 Thrust washer N 2
73 4110000045052 止动垫圈0730.108.304 S=1,9 Thrust washer Y 2
74 4110000045053 止动垫圈0730.108.848 S=1,7 Thrust washer N 2
75 4110000045054 止动垫圈 0730.108.849 S=1,8 Thrust washer N 2
76 4110000045055 止动垫圈 0730.111.728 A=6,8 Thrust washer N 2
77 4110000045056 止动垫圈 0730.111.729 A=7,0 Thrust washer N 2
78 7200001983 六角螺钉 0636.016.083 M 14 *40 Screw Y 48
79 4110000045070 螺塞 4475.280.150 Plug N 2
80 4110000045002 O型圈 0634.304.731 38 * 2,2 O-ring Y 1
81 4110000045058 螺钉 0750.108.075 Screw Y 2
82 7200001864 “O”型圈0634306523 O-ring Y 2
83 7200001877 排气阀0501205154 Valve Y 2
