L959F 转斗缸系统 Tilt cylinder system F1400-2914002377

1 29140019081 放平护板 Plate Y 1

2 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 4

3 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 12

4 4120006001 转斗油缸HSGF-200*105*550-1064B Tilt cylinder Y 1

5 4011001510 螺栓GB16674.1-M12*35flZnyc-8.8-480 Screw Y 16

6 4041000774 螺塞LGB135-01422 Plug Y 2

7 4041000767 O形圈LGB168-11124 O-ring Y 2

8 29140016451 动臂指示板 Indicator plate Y 1

9 4011001246 螺栓GB5783-M8*16flZnyc-8.8-480 Screw Y 2

10 4015000425 垫圈GB96.1-8flZnyc-300HV-480 Washer Y 2

11 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 8

12 29140012931 U形螺栓 U-bolt Y 4

13 4041001018 底板LGB160-3040 Bracket Y 4

14 29140023791 转斗联大腔钢管 Pipe Y 1

15 4041000027 分体法兰LGB117-312551 Flange half Y 2

16 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 7

17 29140023801 转斗联小腔钢管 Pipe Y 1

18 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 8

19 29140020901 转斗缸大腔钢管 Pipe Y 1

20 4011001529 螺栓GB16674.1-M12*55flZnyc-8.8-480 Screw Y 2

21 4011001530 螺栓GB16674.1-M12*60flZnyc-8.8-480 Screw Y 2

22 4011001243 螺栓GB5783-M12*35flZnyc-8.8-480 Screw Y 2

23 29140018961 转斗缸小腔胶管 Hose assembly Y 1

24 4041000144 分体法兰LGB117-312552 Flange half Y 4

25 29140020911 转斗缸大腔胶管 Hose assembly Y 1

26 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 2
