L959F 第三联接口 The 3rd function control unit F1220-2912002303

1 29120016521 三通管接头 Three-way nipple Y 1

2 4030000490 O形圈GB3452.1-10.0*1.80G O-ring Y 1

3 4041001023 组合接头LGB143-01608 Nipple Y 1

4 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 1

5 29120023101 先导回油管 Hose Y 1

6 29120014931 垫圈 Washer Y 6

7 4011001325 螺栓JB999-M14*1.5*32flZnyc-480-35 Bolt Y 2

8 29120015401 接头 Nipple Y 2

9 4011001275 螺栓GB16674.1-M6*16flZnyc-8.8-480 Screw Y 2

10 4015000424 垫圈GB97.1-6flZnyc-300HV-480 Washer Y 1

11 4013000372 螺母GB6170-M6flZnyc-8-480 Nut Y 1

12 4120001966 先导阀总成2TH6L-01 Control lever Y 1

13 29120009351 压板 Plate Y 6

14 29120009361 橡胶板 Rubber plate Y 12

15 4011001262 螺栓GB5782-M10*55flZnyc-8.8-480 Bolt Y 4

16 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 8

17 4011001238 螺栓GB5783-M10*20flZnyc-8.8-480 Screw Y 4

18 29120023051 隔板 Plate Y 2

19 4013000387 螺母GB6173-M30*2flZnyc-05-480 Nut Y 4

20 29120023141 隔板接头 Nipple Y 2

21 29120022651 胶管 Hose Y 2

22 4011001290 螺栓GB5782-M8*55flZnyc-8.8-480 Bolt Y 8

23 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 12

24 29180012931 隔板接头 Nipple Y 2

25 29120036731 丝堵 Plug Y 2

26 4030000062 垫圈JB1002-27-T2 Washer Y 2

27 4030000530 O形圈GB3452.1-6.00*1.80G O-ring Y 2

28 4041001047 组合接头LGB143-01406 Nipple Y 2

29 4041002096 软管LGB126-003280 Hose Y 1

30 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 8

31 4041000027 分体法兰LGB117-312551 Flange half Y 2

32 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 2

33 29120023071 三联阀小腔胶管 Hose Y 1

34 29120023061 三联阀大腔胶管 Hose Y 1

35 29120011601 橡胶管夹 Clamp Y 4

36 29120011591 压板 Plate Y 2

37 4011001287 螺栓GB5782-M8*65flZnyc-8.8-480 Bolt Y 4

38 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 8

39 4041002043 软管LGB126-003210 Hose Y 1

40 4190000176 过渡接头EW10LOMDA3C Nipple Y 1

41 29120023091 先导进油管 Hose Y 1
