L959F 桥壳 4474.101.100 (450202) Axle casing assembly E0720-4110000047

1 7200001787 六角头螺钉0636011464 Screw Y 32

2 4110000047013 垫圈 0730.100.361 Washer Y 32

3 4110000047110 锁紧螺丝M14*40 12.9 0750.108.010 Lock screw Y 16

4 4110000045070 螺塞 4475.280.150 Plug N 1

5 4110000045002 O型圈 0634.304.731 38 * 2,2 O-ring Y 1

6 4110000045071 螺塞 4475.280.042 Plug Y 1

7 7200001793 O型圈 0634.303.266 21*2 O-ring Y 1

8 7200001796 集油挡板4474306139 Baffle plate Y 1

9 7200001797 接头0637870190 Nipple Y 1

10 7200001797 接头0637870190 Nipple Y 2

11 4110000047006 左管 4474.206.026 Tube Y 1

12 7200001799 右管4474206027 Tube Y 1

13 7200001800 圆柱头螺钉0636101024 Screw Y 1

14 4110000047007 圆柱头螺钉 0636.101.554 M 6*12 Screw Y 2

15 4110000047008 垫圈 0630.001.010 6,4 Washer Y 2

16 4110000045072 螺塞 4475.280.140 Plug N 1

17 7200001803 螺塞0899201537 Plug Y 1

18 7200001793 O型圈 0634.303.266 21*2 O-ring Y 1

19 4110000045005 透气垫 0732.612.001 M10*1KEG Spacer Y 1
