L959F 散热器总成（320204） Radiator assembly A0394-4110002506

1 4110002506 散热器总成L959F-V Radiator Y 1

2 4110002506002 导风罩 DB0310 Fan shroud Y 1

3 4110002506003 主框架 KB0312 Framework N 1

4 4110002506004 副框架 KZ9111736B Framework N 1

5 4110002506005 旋转支架 KZ9111736A Radiator bracket Y 1

6 4110002506006 U型密封条 8290011250 Protecting moulding Y 1

7 4110002506007 减震器 729005 Absorber Y 8

8 4110002506008 液压油散 S9111736A Hydraulic oil cooler Y 1

9 4110002506009 中冷器 S9111736B Charge air cooler Y 1

10 4110002506010 水散 S9111736C Radiator Y 1

11 4110002506011 传动油散 S9111736D Oil cooler Y 1

12 4110002506012 六角头螺栓 610347 Screw N 8

13 4110002506013 加大平垫 631430 Washer N 8

14 4110002506014 减震器3mm垫圈 330344 Washer N 4

15 4110002506015 六角头螺栓610342 Screw N 10

16 4110002506016 弹垫632440 Washer N 18

17 4110002506017 平垫630430 Washer N 24

18 4110002506018 六角螺母621340 Nut N 6

19 4110002035002 旋转支架开关QB0147 Lock Y 2

20 4110002506019 2mm橡胶垫圈810018 Washer N 2

21 4110002506020 六角螺母621440 Nut N 8

22 4110002506021 法兰面螺栓614341 Screw N 24

23 4110002506022 六角头螺栓610341 Screw N 8

24 4110002233206 放水阀739001 Drain valve Y 1

25 4110002286007 卡箍990002 Clamp N 1

26 4110002506023 放水管8000080800 Hose Y 1

27 4110002506025 U型密封条8290010170 Protecting moulding Y 2

28 4110002506026 临工标牌700004 Name plate N 1

29 4110002506001 防护网总成 HB0164 Fan guard Y 1
