L959F 快换装置液压系统 Quick coupler hydraulic system G1820-2918001169

1 4120002171 三通接头ET12LOMDCF Three-way nipple Y 1

2 4041001063 组合接头LGB143-01810 Nipple Y 1

3 4041002373 软管LGB128-005285 Hose assembly Y 1

4 4041000150 直接头LGB120-01814 Nipple Y 1

5 4041000767 O形圈LGB168-11124 O-ring Y 9

6 4041000604 直接头LGB120-01614 Nipple Y 6

7 4041001848 软管LGB125-004058 Hose assembly Y 1

8 29180012371 隔板 Plate Y 1

9 29180010621 橡胶板 Rubber plate N 4

10 29180010631 压板 Anchor plate Y 2

11 4011001280 螺栓GB5783-M10*40flZnyc-8.8-480 Screw Y 2

12 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 4

13 4041002033 软管LGB127-004280 Hose Y 1

14 4041001023 组合接头LGB143-01608 Nipple Y 1

15 4041001689 软管LGB128-004290 Hose Y 1

16 29180012381 管夹 Clamp Y 4

17 29180012411 压板 Plate Y 2

18 4011001334 螺栓GB5782-M8*90flZnyc-8.8-480 Screw Y 4

19 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 4

20 29180012401 隔板接头 Nipple Y 2

21 4013000378 螺母GB6173-M16*1.5flZnyc-05-480 Nut Y 2

22 4041002113 软管LGB127-204165 Hose Y 2

23 4120001741 液压锁BQ2201-7E Check valve Y 1

24 4014000527 螺钉GB70.1-M8*45flZnyc-8.8-480 Screw Y 2

25 4015000036 垫圈GB93-8-65Mn Spring washer Y 2

26 4041000133 直接头LGB120-01414 Nipple Y 2

27 29180012391 隔板接头 Nipple Y 1

28 29180012921 隔板接头 Nipple Y 1

29 4013000380 螺母GB6173-M14*1.5flZnyc-05-480 Nut Y 2

30 4015000435 垫圈GB97.1-14flZnyc-300HV-480 Washer Y 2

31 4120004913 双杆缸HSGF-50*30*135-460 Hydraulic cylinder Y 1

32 4011001244 螺栓GB16674-M12*40flZnyc-8.8-480 Screw Y 4

33 29180012441 调整垫片 Shim Y 4

34 29180012451 调整垫片 Shim Y 4

35 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 3

36 29180009381 板 Plate Y 1

37 4120000368 电磁阀4WE6E61B/CG24NZ4B08 Solenoid valve Y 1

38 29180007862 电磁阀座 Valve seat Y 1

39 4014000513 螺钉GB70.1-M8*30flZnyc-8.8-480 Screw Y 4

40 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 2

41 29180012331 胶管 Hose assembly Y 1

42 29180012341 胶管 Hose assembly Y 1

43 4041002305 软管LGB128-003041 Hose assembly Y 1

44 4041002306 软管LGB128-003030 Hose assembly Y 1

45 29180010721 快换操纵标志 Decal Y 1

46 26370001921 管夹 Clamp N 1

47 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 1
