L959F 右台架总成 Platform assembiy M3440-2934003537

1 29340037221 右后扶手 Hand rail Y 1

2 4011001250 螺栓GB5783-M12*30flZnyc-8.8-480 Screw Y 8

3 4015000427 垫圈GB96.1-12flZnyc-300HV-480 Washer Y 18

4 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 2

5 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 2

6 29340034041 右台架 Platform Y 1

7 29340027852 右前扶手 Hand rail Y 1

8 4011001249 螺栓GB5783-M10*30flZnyc-8.8-480 Screw Y 6

9 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 10

10 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 5

11 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2

12 29340037181 支架 Bracket Y 1

13 29340035411 右爬梯总成 Ladder Y 1

14 4011001332 螺栓GB5782-M12*80flZnyc-8.8-480 Screw Y 4

15 29340024971 外压板 Plate Y 1

16 4011001270 螺栓GB5783-M10*35flZnyc-8.8-480 Screw Y 3

17 29340041131 橡胶板 Rubber plate Y 1

18 4011001243 螺栓GB5783-M12*35flZnyc-8.8-480 Screw Y 6

19 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 1
