L952D 输出轴总成 Output shaft C0510-2905002356

1 4011001358 螺栓GB5783-M1030flZnyc-10.9-480 Screw Y 2 2 4015000384 防松垫圈NASM1312-7-NL10 Washer Y 2 3 29050011161 垫圈 Washer Y 1 4 4030000536 O形圈GB3452.1-1223.55G O-ring Y 4
5 29050017481 油封座 Sealing retainer Y 2
6 4021000285 滚动轴承GB292-7312ACM Bearing Y 2
7 29050023552 输出轴 Output shaft Y 1
8 29050016311 输出轴齿轮 Gear Y 1
9 29050016931 挡圈 Retaining ring Y 2
10 4030000768 密封圈GB13871.1-FB070095-F Sealing ring Y 2
11 7100002101 O形圈GB3452.1-54.5*2.65G O-ring Y 2
12 29050023541 螺母 Nut Y 1
13 29070000221 垫圈 Washer Y 1
14 29050012751 调整垫片 Shim Y 2
15 29050012741 调整垫片 Shim Y 2
16 29050012731 调整垫片 Shim Y 2
17 29050025851 密封套 Sealing sleeve Y 2
