L952D 转向器总成 Diverter I2000-2920001175

1 4120006531 转向器Xcel80-800 Diverter valve Y 1

2 4011001375 螺栓GB16674.1-M12*30flZnyc-8.8-480 Bolt Y 4

3 4011001298 螺栓GB16674.1-M10*55flZnyc-8.8-480 Screw Y 4

4 29310024341 固定架 Bracket Y 1

5 4120005406 转向柱LG20-ZXZ-28 Steering column Y 1

6 4120000018 方向盘FXP-50F Steering wheel Y 1

7 4041002396 软管LGB129-010079 Hose assembly Y 1

8 4041002700 软管LGB126-010084 Hose assembly Y 1

9 4011000528 螺栓GB16674-M10*100EpZn-8.8 Bolt Y 2

10 29310011301 调整座 Block Y 2

11 29310011251 固定板 Anchor plate Y 2

12 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 2

13 4041000084 直接头LGB155-01214 Nipple Y 2

14 4030000285 O形圈GB3452.1-12.5*2.65G O-ring Y 2

15 29200009771 组合接头 Elbow nipple Y 1

16 4041000088 直接头LGB155-23326 Nipple Y 1

17 4030000276 O形圈GB3452.1-32.5*2.65G O-ring Y 1

18 4041002519 软管LGB128-003100 Hose assembly Y 1

19 4041000131 直接头LGB120-01412 Nipple Y 1

20 4041000784 O形圈LGB168-10924 O-ring Y 1

21 4041001047 组合接头LGB143-01406 Nipple Y 1

22 4030000530 O形圈GB3452.1-6.00*1.80G O-ring Y 1

23 4011001354 螺栓GB5782-M10*90flZnyc-8.8-480 Screw Y 2

24 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 8

25 4120002116 优先阀VLE-150S Priority valve Y 1

26 4041001751 软管LGB124-003070 Hose Y 1

27 4190001832 扎丝RTGB-200ST Cable tie Y 3

28 4041000796 直接头LGB120-02628 Nipple Y 1

29 4041000779 O形圈LGB168-12331 O-ring Y 1

30 4041000133 直接头LGB120-01414 Nipple Y 1

31 4041000767 O形圈LGB168-11124 O-ring Y 1
32 4041000564 直接头LGB120-02620 Nipple Y 2
33 4041000783 O形圈LGB168-11724 O-ring Y 3
34 29200007901 直接头 Nipple Y 1
35 4041000132 直接头LGB120-02220 Nipple Y 1
