L952D 液压油箱系统 Hydraulic fluid tank system F1000-2910003060

1 29100030611 液压油箱 Hydraulic fluid tank Y 1
2 4041001272 直接头LGB120-03628 Nipple Y 1
3 4041000779 O形圈LGB168-12331 O-ring Y 1
4 29100028791 钢管 Pipe Y 1
5 4030000504 O形圈GB3452.1-25.81.80G O-ring Y 1 6 4120000756 胶管JB8406-B251200 Hose Y 1
7 4017000008 喉箍JB8870-d40 Clamp Y 2
8 4120001088 换气过滤器L1.0807-31 Breather cap Y 1
9 29100020221 \呼吸器固定座 Seat Y 1
10 4011001238 螺栓GB5783-M1020flZnyc-8.8-480 Screw Y 2 11 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2 12 4011001511 螺栓GB5783-M1640flZnyc-8.8-480 Bolt Y 7
13 29100011031 垫圈 Washer Y 7
