L948F 输入装置 4644 102 134 Input shaft C0542-4110001742

1 4110000367063 涡轮轴 4644 302 188 Shaft Y 1

2 7200001471 张紧销钉(2.5×5)0631329267 Pin Y 1

3 7200001472 张紧销钉(1.5×5)0631329124 Pin Y 1

4 4110000367064 球轴承 6308 C3 40*90*23 0750 116 139 Bearing Y 1

5 4110001742007 调整垫圈 4607 302 006-014,033,034 Shim Y 1

6 7200001475 卡环0630501031 Lock ring Y 1

7 7200001476 主动齿轮(Z=52)4644302206 Gear Y 1

8 4110000367067 滚柱轴承J209E/C3 45*85*19 0750 118 Bearing Y 1

9 4110000076256 搭扣密封环0734317252 Sealing ring Y 1

10 7200001479 进油法兰4644302250 Flange Y 1

11 7200001480 密封垫4644302211 Gasket Y 1

12 7200001481 轴承盖4642301136 Cover plate Y 1

13 7200001482 密封垫4644301262 Gasket Y 1

14 7200001483 六角螺钉(M8x28)0636015092 Screw Y 8

15 4110000076027 搭扣密封环0734 401 078 Sealing ring Y 1

16 4110000367070 滚针轴承HK75*83*16 0735 298 027 Needle bearing Y 1

17 4110000076367 轴用密封圈 0750 111 231 75*100*10 Sealing ring Y 1

18 7200001487 输出轴4644311239 Output shaft Y 1

19 7200001488 活塞环(30×2)0634402025 Piston ring Y 1

20 7200001489 密封垫4644301265 Gasket Y 1

21 4110000042013 齿轮泵0750 132 143 Gear pump Y 1

22 4110000367073 球轴承6206RS/J30*62*16 0750 116 104 Bearing Y 1

23 7200001492 滑键(A6x4x28)0631501052 Key Y 1

24 4110000367073 球轴承6206RS/J30*62*16 0750 116 104 Bearing Y 1

25 4110001742008 调整垫圈 0730 001 591-600 Shim Y 1

26 7200001495 六角螺钉(M8x85)0636010111 Screw Y 4

27 7200001496 六角螺钉(M8x115)0636010123 Screw Y 4

28 7200001497 卡环 30×1.50630501024 Lock ring Y 2
