L948F 轮边减速器 Hub reduction E0712-2907002348

1 29070001231 油封端盖 Sealing cover Y 1

2 4021000037 滚动轴承GB297-32221 Roller bearing Y 1

3 29070000481 驱动桥内齿轮 Gear ring Y 1

4 29070001241 轮毂 Hub Y 1

5 4041000020 O形圈LGB308-440*3.5 O-ring Y 1

6 29070021441 磁性螺塞 Plug Y 1

7 29070007611 行星轮架 Planet carrier Y 1

8 4011001249 螺栓GB5783-M10*30flZnyc-8.8-480 Screw Y 10

9 4015000025 垫圈GB93-10-65Mn Spring washer Y 10

10 4014000016 螺钉GB70-M10*1*20EpZn-8.8 Screw Y 2

11 29070009161 定位块 Block Y 1

12 4015000022 挡圈GB894.1-52-65Mn Retaining ring Y 1

13 29070000511 太阳齿轮 Sun gear Y 1

14 29070007621 盖 Cover Y 1

15 29070012351 垫片 Shim Y 6

16 29070012361 垫片 Shim Y 6

17 29070000551 挡环 Retaining ring Y 6

18 4090000004 滚针GB309-5*45-GCr15 Needle roller Y 93

19 29070000561 行星齿轮 Planet gear Y 3

20 29070000571 圆螺母 Round nut N 1

21 4021000033 滚动轴承GB297-32024 Roller bearing Y 1

22 29070001261 隔套 Spacer sleeve Y 1

23 29070001271 垫片 Shim Y 1

24 4030000047 骨架油封HG4-692-PD150*180*16 Sealing ring Y 1

25 4011001321 螺栓GB5782-M8*45flZnyc-8.8-480 Screw Y 6

26 4015000036 垫圈GB93-8-65Mn Spring washer Y 6

27 29070009281 半轴 Shaft half Y 1

28 29070000611 行星齿轮轴 Planet gear shaft Y 3

29 4090000008 钢球GB308-9.525-GCr15 Ball Y 3

30 29070021471 轮辋螺栓 Screw Y 10

31 4015000030 垫圈GB93-20-65Mn Spring washer Y 10
32 4090000006 钢球GB308-17.462-GCr15 Ball Y 1
33 4013000382 螺母GB6171-M20*1.5flZnyc-10-480 Nut Y 1
