L948F 转向缸总成 Steering cylinder system I2100-2921001135

1 29210010731 钢管 Pipe Y 1

2 4030000275 O形圈GB3452.1-22.4*3.55G O-ring Y 2

3 4011001301 螺栓GB16674.1-M8*30flZnyc-8.8-480 Screw Y 4

4 4011001425 螺栓GB16674.1-M8*40flZnyc-8.8-480 Bolt Y 4

5 29210010331 钢管 Pipe Y 1

6 4041001746 软管LGB128-406078 Hose assembly Y 2

7 29210009431 转向缸进油胶管 Hose assembly Y 2

8 4120005977 转向油缸HSGL-80*45*327-594 Steering cylinder Y 2

9 29210004061 固定座 Bracket Y 1

10 29210004071 橡胶板 Rubber plate Y 2

11 4011001424 螺栓GB5782-M10*70flZnyc-8.8-480 Screw Y 1

12 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 1
