L948F 液压操纵总成 Hydraulic control assembly F1200-2912002779

1 29120026281 先导阀回油胶管M16-M18 Hose assembly Y 1

2 4041002256 软管LGB124-004090 Hose assembly Y 1

3 29120010341 直通接头 Nipple Y 5

4 29120013381 垫圈 Washer Y 7

5 4015000437 垫圈GB96.1-6flZnyc-300HV-480 Washer Y 4

6 4011001284 螺栓GB16674.1-M6*40flZnyc-8.8-480 Screw Y 6

7 4013000372 螺母GB6170-M6flZnyc-8-480 Nut Y 4

8 4120002935 先导阀总成HC-RCL-5A-VIA Control valve Y 1

9 29120021751 直通接头 Nipple Y 2

10 4041000056 分体法兰LGB117-312550 Flange half Y 4

11 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 5

12 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 28

13 4041002452 软管LGB161-012130 Hose assembly Y 1

14 29120029061 回油块 Block Y 1

15 4011001241 螺栓GB5783-M12*25flZnyc-8.8-480 Screw Y 2

16 4015000427 垫圈GB96.1-12flZnyc-300HV-480 Washer Y 2

17 4041000205 软管LGB162-012125 Hose Y 1

18 4041000958 U形螺栓LGB159-03040 U-bolt Y 1

19 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 2

20 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2

21 4041000767 O形圈LGB168-11124 O-ring Y 3

22 4041000774 螺塞LGB135-01422 Plug Y 3

23 4041000010 分体法兰LGB117-314651 Flange half Y 1

24 4030000130 O形圈GB3452.1-47.5*3.55G O-ring Y 2

25 29120021941 多路阀进油钢管 Pipe Y 1

26 4011001506 螺栓GB5782-M12*165flZnyc-8.8-480 Screw Y 2

27 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 5

28 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 5

29 4011001465 螺栓GB5782-M12*145flZnyc-8.8-480 Screw Y 1

30 4030000182 多路阀D32A-18 Control valve Y 1

31 29120014931 垫圈 Washer Y 12

32 29120007651 接头 Nipple Y 4

33 4041002186 软管LGB128-004295 Hose Y 1

34 4041002252 软管LGB128-004240 Hose assembly Y 1

35 29120015401 接头 Nipple Y 4

36 4041001047 组合接头LGB143-01406 Nipple Y 1

37 4030000530 O形圈GB3452.1-6.00*1.80G O-ring Y 1

38 4041000027 分体法兰LGB117-312551 Flange half Y 1

39 29120011391 固定支架 Bracket Y 1

40 4011001371 螺栓GB16674.1-M12*35flZnyc-10.9-480 Bolt Y 6

41 4041002180 软管LGB125-003320 Hose Y 1

42 4041002181 软管LGB125-003285 Hose Y 1

43 4041002247 软管LGB125-004310 Hose assembly Y 1

44 4041002248 软管LGB125-004265 Hose assembly Y 1

45 4120001954 滤油器PLF-C30*10 Hydraulic fluid filter Y 1

46 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 4

47 29120016021 固定板 Anchor plate Y 1

48 4041001575 软管LGB125-004060 Hose assembly Y 1

49 29120015081 接头 Nipple Y 2

50 4030000276 O形圈GB3452.1-32.5*2.65G O-ring Y 2

51 4041001023 组合接头LGB143-01608 Nipple Y 3

52 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 3

53 4120002679 溢流阀块1010375-35 Relief valve Y 1

54 4011001315 螺栓GB16674.1-M6*45flZnyc-8.8-480 Screw Y 2

55 4041000766 直接头LGB120-01818 Nipple Y 3

56 4041000768 O形圈LGB168-11524 O-ring Y 3

57 4120001901 接头GE12LM18*1.5EDOMDA3C Nipple Y 2

58 4041000505 软管LGB125-005138 Hose assembly Y 1

59 29120016521 三通管接头 Three-way nipple Y 1

60 29220017621 直接头1-1/16-12UN-M18 Nipple Y 1

61 4041000152 软管LGB125-005120 Hose assembly Y 1

62 4041000814 软管LGB128-004090 Hose assembly Y 1

63 4120005063 压力选择阀SF8-D Valve Y 1

64 4011001212 螺栓GB16674.1-M10*55flZnyc-10.9-480 Screw Y 2

65 26010005081 接头 Nipple Y 1

66 4041000660 软管LGB125-005100 Hose assembly Y 1

67 29120021011 固定板 Anchor plate Y 1

68 4011001247 螺栓GB5783-M8*20flZnyc-8.8-480 Screw Y 2

69 4015000425 垫圈GB96.1-8flZnyc-300HV-480 Washer Y 2

70 4120004696 直通接头1CO-16-06 Nipple Y 2

71 4041002251 软管LGB125-004088 Hose assembly Y 1

72 4120005540 换向阀SV08-20MS-6T-N-24ER Control valve Y 1

73 4011001240 螺栓GB16674-M12*25flZnyc-8.8-480 Screw Y 4

74 29120016351 固定板 Anchor plate Y 2

75 29120021551 管夹 Clamp Y 4

76 29120016951 固定板 Anchor plate Y 2

77 4011001303 螺栓GB16674.1-M8*90flZnyc-8.8-480 Screw Y 4

78 29120025621 多路阀进油胶管 Hose Y 1

79 4190000020 扎丝LG13-ZS4*250 Cable tie Y 58

80 26370002901 自扎帆布套 Tarpaulin cover Y 1

81 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 1

82 4041000043 分体法兰LGB117-310490 Flange half Y 1

83 29120028111 多路阀回油钢管 Pipe Y 1

84 4030000241 O形圈GB3452.1-20.0*1.80G O-ring Y 1

85 4041000680 堵塞LGB142-03016 Plug Y 1

86 29120007671 管夹 Clamp Y 3

87 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 3

88 4120001954001 滤芯（先导滤清器滤芯)PLFX-30X10 Filter insert Y 1
