L948F 发动机连接总成4644 130 296 Flange plate C0540-4110001742

1 4110001742003 变矩器壳体 4644 330 386 Housing Y 1

2 7200001454 六角螺钉(M10*50)0636010460 Screw Y 14

3 4110000042124 张紧销钉0631 329 100 Pin Y 2

4 7200001456 张紧销钉0631329072 Pin Y 2

5 7200001457 盖4139301485 Cover Y 1

6 4110001742004 O形圈 0634 306 287 O-ring Y 1

7 4110001742005 挡板 4644 330 216 Plate Y 2

8 4110000076376 螺栓0636 015 280 M10*18 DIN933 10.9 Screw Y 4

9 7200001460 垫圈4644330228 Washer Y 1

10 7200002202 垫圈(10.5)0630001014 Washer Y 4

11 4110000076308 垫圈4166 330 123 Washer Y 1

12 7200001463 O形圈(25×3)0634313260 O-ring Y 1

13 7200001464 卡环(30×1.2)0630502015 Lock ring Y 1

14 7200001465 盖4644330242 Cover Y 1

15 7200001466 六角螺钉(M10x12)0636015169 Screw Y 4

16 4110000042125 中间环4644 330 222 Flange Y 1

17 7200001468 螺钉(M12x30)0636900127 Screw Y 12
