L948F 发动机罩总成 Bonnet M3310-2933006172

1 29330061782 发动机罩 Hood N 1

2 29330061851 窗棂衬网 Protecting grating Y 1

3 4011001285 螺栓GB5783-M6*16flZnyc-8.8-480 Screw Y 10

4 4015000437 垫圈GB96.1-6flZnyc-300HV-480 Washer Y 10

5 29330031081 橡胶套D50 Rubber sleeve Y 2

6 29360015191 后标志 Emblem Y 1

7 4015000427 垫圈GB96.1-12flZnyc-300HV-480 Washer Y 4

8 4011001241 螺栓GB5783-M12*25flZnyc-8.8-480 Screw Y 4

9 29330020211 垫片 Spacer Y 2

10 29330020221 垫片 Spacer Y 2

11 29330062812 右后扶手 Hand rail Y 1

12 29330062792 左后扶手 Hand rail Y 1

13 29330053091 后支腿垫片 Shim Y 2

14 29330053101 后支腿垫片 Shim Y 2

15 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 4

16 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 4

17 29330062781 门锁卡板 Lock plate Y 2

18 29330023151 垫圈12 Washer Y 6

19 4043003375 防松套LGB331-12*30*30EpZn-45 Attaching sleeve Y 6

20 4011001252 螺栓GB5783-M12*60flZnyc-8.8-480 Bolt Y 6

21 4011001249 螺栓GB5783-M10*30flZnyc-8.8-480 Screw Y 4

22 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 4

23 29330063611 后视镜支架 Bracket Y 1

24 14401305 镜子 Mirror Y 1
