L956FH 转向泵总成 Steering pump assembly I1900-2919001543

1 4017000013 喉箍JB8870-d90 Clamp Y 4

2 29190015471 转向泵吸油胶管 Hose Y 1

3 4120008095 齿轮泵HPT3-125/P124-10 Gear pump Y 1

4 29110000043 泵用密封垫 Gasket Y 1

5 4012000100 螺柱GB898-M12*35flZnyc-10.9-480 Stud Y 4

6 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 4

7 4013000397 螺母GB6170-M12flZnyc-10-480 Nut Y 4

8 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 2

9 4041000027 分体法兰LGB117-312551 Flange half Y 1

10 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 8

11 29190015461 优先阀进油胶管 Hose assembly Y 1

12 4030000163 O形圈GB3452.1-58.0*3.55G O-ring Y 1

13 4011001312 螺栓GB16674.1-M12*65flZnyc-8.8-480 Screw Y 4

14 29190015481 转向泵吸油钢管 Pipe Y 1

15 4041000766 直接头LGB120-01818 Nipple Y 2

16 4041000768 O形圈LGB168-11524 O-ring Y 2

17 4041001063 组合接头LGB143-01810 Nipple Y 1

18 4041000604 直接头LGB120-01614 Nipple Y 1

19 4041000767 O形圈LGB168-11124 O-ring Y 1

20 4041002749 软管LGB126-004095 Hose assembly Y 1

21 4041001023 组合接头LGB143-01608 Nipple Y 1

22 29190015521 转向泵出油块 Block Y 1

23 4011001463 螺栓GB16674.1-M10*75flZnyc-8.8-480 Bolt Y 4

24 4041000043 分体法兰LGB117-310490 Flange half Y 1

25 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 1

26 4041002818 软管LGB166-005095 Hose assembly Y 1
