L953 液压操纵总成 Hydraulic control assembly F1200-2912003101

1 29120030871 回油钢管 Pipe Y 1

2 4030000130 O形圈GB3452.1-47.5*3.55G O-ring Y 3

3 4011001375 螺栓GB16674.1-M12*30flZnyc-8.8-480 Bolt Y 4

4 29120031441 多路阀回油胶管 Hose assembly Y 1

5 4041000011 分体法兰LGB117-314650 Flange half Y 2

6 4011001510 螺栓GB16674.1-M12*35flZnyc-8.8-480 Screw Y 12

7 29120030901 支架 Bracket Y 1

8 4011001299 螺栓GB16674.1-M10*25flZnyc-8.8-480 Screw Y 2

9 29120030911 橡胶管夹 Clamp Y 1

10 29120032701 U型板固定板 Plate Y 1

11 4011001393 螺栓GB5782-M8*100flZnyc-8.8-480 Bolt Y 2

12 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 4

13 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

14 4041000774 螺塞LGB135-01422 Plug Y 2

15 4041000767 O形圈LGB168-11124 O-ring Y 2

16 4011001558 螺栓GB5782-M12*175flZnyc-8.8-480 Screw Y 1

17 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 8

18 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 8

19 29120009161 多路阀回油钢管 Pipe Y 1

20 4030000031 O形圈GB3452.1-42.5*3.55G O-ring Y 1

21 4011001560 螺栓GB16674.1-M10*65flZnyc-8.8-480 Screw Y 1

22 4011001465 螺栓GB5782-M12*145flZnyc-8.8-480 Screw Y 1

23 4120002314 多路阀DFS-32-18 Control valve Y 1

24 29120009112 护板 Protecting plate Y 1

25 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 2

26 4011001561 螺栓GB5782-M12*135flZnyc-8.8-480 Screw Y 2

27 29120019061 多路阀进油块 Valve block Y 1

28 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 3

29 4011001563 螺栓GB16674.1-M10*85flZnyc-8.8-480 Screw Y 4

30 29120030751 多路阀进油胶管 Hose assembly Y 1

31 4041000056 分体法兰LGB117-312550 Flange half Y 2
32 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 12
33 29120009141 多路阀固定板 Anchor plate Y 1
34 29120030761 操纵软轴 Flexible shaft Y 2
35 4120003865 操纵机构 LG12-953CZJG03 Control mechanism Y 1
