L946 Electric equipment P4400-2944000294

L946 Electric equipment P4400-2944000294

1 4190001832 扎丝RTGB-200ST Cable tie Y 8
2 4011001294 螺栓GB16674.1-M1020flZnyc-8.8-480 Screw Y 5 3 4011001297 螺栓GB16674.1-M816flZnyc-8.8-480 Screw Y 2
4 14400342 扎带 Strip clamp Y 4
5 26370001072 支架 Bracket Y 2
6 29440001961 ECU线束 Wiring harness Y 1
7 4041002417 管夹LGB169-B2012.5 Clamp Y 2 8 4011001337 螺栓GB16674.1-M1220flZnyc-8.8-480 Screw Y 2
9 4045000032 电瓶线LGB340-50450P1L10L10-4 Battery cable Y 1 10 4190001839 扎丝LG13-ZS4160 Cable tie Y 9
11 4015000424 垫圈GB97.1-6flZnyc-300HV-480 Washer Y 7
12 29440000161 过渡板 Plate Y 1
13 4011001275 螺栓GB16674.1-M616flZnyc-8.8-480 Screw Y 3 14 4130001081 电子油门踏板WL400244 Accelerator pedal Y 1 15 4011001276 螺栓GB16674.1-M620flZnyc-8.8-480 Screw Y 4
16 4013000372 螺母GB6170-M6flZnyc-8-480 Nut Y 4
17 4130002655 多态开关3735075-BD01 Switch Y 1
