L946 转向泵总成(370142) Steering pump assembly I1901-4120002117

1 4120000171044 挡圈41060100200 Retaining ring Y 1

2 4120000171046 挡圈41060100100 Retaining ring Y 1

3 4120000171045 旋转轴唇形密封圈43020200100 Sealing ring Y 2

4 4120002117001 前盖21020200110 Cover Y 1

5 4120000171048 环形密封圈 44020100300 Sealing ring Y 2

6 4120000171049 滚针轴承42010100100 Needle bearing Y 4

7 4120000171050 定位套21020900110 Spacer sleeve Y 4

8 4120000171051 耳形挡片21020800110 Retaining ring Y 2

9 4120000171052 耳形密封垫21020700110 Sealing washer Y 2

10 4120000171053 侧板21020600110 Side board Y 2

11 4120002117002 主动齿轮轴21020110110 Drive shaft Y 1

12 4120005048005 从动齿轮轴21020410010 Shaft Y 1

13 4120002117003 泵体21020310010 Pump body Y 1

14 4120001060003 后盖21020500110 Cover Y 1

15 4120002117005 螺钉44010101280 Screw Y 4

16 4120001715017 螺钉41010101780 Screw Y 4

17 4120000171043 弹簧垫圈41050200600 Spring washer Y 4

18 4120001715018 弹簧垫圈41050200500 Spring washer Y 4

19 4120002117006 密封件包 Sealing ring kit Y 1
