L946 液压操纵总成 Hydraulic control assembly F1200-2912003443

1 4041000774 螺塞LGB135-01422 Plug Y 2

2 4041000767 O形圈LGB168-11124 O-ring Y 2

3 4011001558 螺栓GB5782-M12*175flZnyc-8.8-480 Screw Y 1

4 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 8

5 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 8

6 4011001560 螺栓GB16674.1-M10*65flZnyc-8.8-480 Screw Y 1

7 4011001465 螺栓GB5782-M12*145flZnyc-8.8-480 Screw Y 3

8 4120003809 多路阀DFSY-32-16 Control valve Y 1

9 29120028531 多路阀固定板 Plate Y 1

10 29120005021 多路阀回油钢管 Pipe Y 1

11 4030000130 O形圈GB3452.1-47.5*3.55G O-ring Y 1

12 4041000705 软管LGB163-012112 Hose assembly Y 1

13 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 28

14 4041000056 分体法兰LGB117-312550 Flange half Y 5

15 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 5

16 4041000043 分体法兰LGB117-310490 Flange half Y 2

17 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 2

18 4041000698 软管LGB107-010125 Hose assembly Y 1

19 4011001296 螺栓GB16674.1-M8*20flZnyc-8.8-480 Screw Y 6

20 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

21 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 4

22 29120015431 管夹 Clamp Y 2

23 4041001188 缓冲套LGB123-0219 Rubber sleeve Y 2

24 4041000869 缓冲套LGB123-0740 Rubber sleeve Y 2

25 29120015711 管夹 Clamp Y 2

26 29120034451 滤油器固定板 Plate Y 1

27 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 4

28 4120001954 滤油器PLF-C30*10 Hydraulic fluid filter Y 1

29 4190000020 扎丝LG13-ZS4*250 Cable tie Y 6

30 29120017011 三通接头 Three-way nipple Y 1

31 4120002271 单向阀S8A120S Check valve Y 1

32 29120015221 垫圈 Washer Y 3

33 4011001299 螺栓GB16674.1-M10*25flZnyc-8.8-480 Screw Y 4

34 29120034441 蓄能器固定板 Plate Y 1

35 4041000598 堵塞LGB142-01604 Plug Y 1

36 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 3

37 4041001063 组合接头LGB143-01810 Nipple Y 1

38 4030000490 O形圈GB3452.1-10.0*1.80G O-ring Y 1

39 4190000143 三通接头EL12LOMDA3C Three-way nipple Y 1

40 4041000532 软管LGB162-012105 Hose assembly Y 1

41 29120017231 U形螺栓 U-bolt Y 1

42 4015000425 垫圈GB96.1-8flZnyc-300HV-480 Washer Y 2

43 29120017111 缓冲套 Rubber sleeve Y 1

44 4120002274 蓄能器GXQ-D-0.75L-100 Accumulator Y 1

45 29120017241 直接头 Nipple Y 1

46 29220000811 垫圈 Washer Y 1

47 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 8

48 29120005101 固定支架 Bracket Y 1

49 29120004051 多路阀进油钢管 Pipe Y 1

50 4041000958 U形螺栓LGB159-03040 U-bolt Y 1

51 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 6

52 4011001509 螺栓GB16674.1-M12*45flZnyc-8.8-480 Bolt Y 4

53 29120014931 垫圈 Washer Y 13

54 29120015401 接头 Nipple Y 8

55 4041002180 软管LGB125-003320 Hose Y 1

56 4041001023 组合接头LGB143-01608 Nipple Y 2

57 29120007651 接头 Nipple Y 1

58 29120035591 软管 Hose assembly Y 1

59 4041001047 组合接头LGB143-01406 Nipple Y 1

60 4030000530 O形圈GB3452.1-6.00*1.80G O-ring Y 1

61 4041002269 软管LGB125-003385 Hose assembly Y 1

62 4041001453 软管LGB125-003255 Hose assembly Y 1

63 4041002183 软管LGB125-003265 Hose Y 1

64 4011001510 螺栓GB16674.1-M12*35flZnyc-8.8-480 Screw Y 4

65 29120016371 固定弯板 Plate Y 2

66 29120016351 固定板 Anchor plate Y 2

67 29120016741 管夹 Clamp Y 4

68 4011001303 螺栓GB16674.1-M8*90flZnyc-8.8-480 Screw Y 4

69 4011001337 螺栓GB16674.1-M12*20flZnyc-8.8-480 Screw Y 2

70 29120013521 固定板 Anchor plate Y 1

71 29120016771 钢管 Pipe Y 1

72 4011000556 U形螺栓JB/ZQ4321-33Zn-Q235A.F U-bolt Y 2

73 29120004041 二通块 Valve block Y 1

74 4120006656 先导阀总成GDXS2-DT Control lever Y 1

75 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 6

76 29120017131 先导阀进油软管 Hose assembly Y 1

77 4011000344 螺栓JB999-M14*1.5*32EpZn-35 Bolt Y 1

78 29120024241 先导回油管 Hose Y 1

79 4011000366 螺栓JB999-M18*1.5*40EpZn-35 Bolt Y 1

80 29120015081 接头 Nipple Y 2

81 4030000276 O形圈GB3452.1-32.5*2.65G O-ring Y 2

82 4041000712 软管LGB124-004059 Hose assembly Y 1

83 29120007671 管夹 Clamp Y 3

84 29120035581 空心螺栓M14*1.5 Bolt Y 1
