L955FC 转向泵总成 Steering pump system I1900-2919001600

1 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 8

2 4041000043 分体法兰LGB117-310490 Flange half Y 1

3 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 1

4 29190015131 转向泵出油胶管 Hose assembly Y 1

5 29190015141 出油钢管 Pipe Y 1

6 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 2

7 4011001298 螺栓GB16674.1-M10*55flZnyc-8.8-480 Screw Y 4

8 4120008462 双联泵100/10 Gear pump Y 1

9 29110000043 泵用密封垫 Gasket Y 1

10 4012000100 螺柱GB898-M12*35flZnyc-10.9-480 Stud Y 4

11 4013000397 螺母GB6170-M12flZnyc-10-480 Nut Y 4

12 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 4

13 29190014751 转向泵吸油胶管 Hose Y 1

14 4017000013 喉箍JB8870-d90 Clamp Y 4

15 29190014742 转向泵吸油钢管 Pipe Y 1

16 4030000482 O形圈GB3452.1-50.0*3.55G O-ring Y 1

17 4011001530 螺栓GB16674.1-M12*60flZnyc-8.8-480 Screw Y 4

18 29110011921 直接头M16-M16 Nipple Y 1

19 4041000780 O形圈LGB168-11324 O-ring Y 1

20 4041002251 软管LGB125-004088 Hose assembly Y 1

21 4041001023 组合接头LGB143-01608 Nipple Y 1

22 4041000027 分体法兰LGB117-312551 Flange half Y 1
