L955FC 转向器总成 Steering gear system I2000-2920001136

1 4041000709 直接头LGB120-01616 Nipple Y 1

2 4041000780 O形圈LGB168-11324 O-ring Y 1

3 29200011431 优先阀回油胶管 Hose assembly Y 1

4 29200011391 优先阀VLE-150S部装总成 Priority valve N 1

5 4011001354 螺栓GB5782-M10*90flZnyc-8.8-480 Screw Y 2

6 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2

7 4030000501 O形圈GB3452.1-15.0*1.80G O-ring Y 1

8 4041001006 组合接头LGB143-02616 Nipple Y 1

9 4041002585 软管LGB127-010085 Hose assembly Y 1

10 4041002519 软管LGB128-003100 Hose assembly Y 1

11 4030000530 O形圈GB3452.1-6.00*1.80G O-ring Y 1

12 4041001047 组合接头LGB143-01406 Nipple Y 1

13 29200011381 转向器Xcel80-800部装 Diverter N 1

14 29200012111 转向柱部装总成 Steering column N 1

15 29200011401 支架 Bracket Y 1

16 29200011411 橡胶管夹 Clamp Y 1

17 29200011421 U型固定板 Plate Y 1

18 4011001512 螺栓GB5782-M8*60flZnyc-8.8-480 Bolt Y 1

19 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 1

20 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 1

21 29200011441 转向器回油胶管 Hose assembly Y 1

22 4041000188 直接头LGB120-03028 Nipple Y 1

23 4041000779 O形圈LGB168-12331 O-ring Y 1

24 4120006531 转向器Xcel80-800 Diverter valve Y 1

25 4041000783 O形圈LGB168-11724 O-ring Y 4

26 4041000564 直接头LGB120-02620 Nipple Y 2

27 4041000132 直接头LGB120-02220 Nipple Y 2

28 4041000131 直接头LGB120-01412 Nipple Y 1

29 4041000784 O形圈LGB168-10924 O-ring Y 1

30 4120002116 优先阀VLE-150S Priority valve Y 1

31 4030000285 O形圈GB3452.1-12.5*2.65G O-ring Y 2

32 4041000084 直接头LGB155-01214 Nipple Y 2

33 4041000088 直接头LGB155-23326 Nipple Y 1

34 4030000276 O形圈GB3452.1-32.5*2.65G O-ring Y 1
