L955FC 多路阀(331005) Control valve F1201-4120007617

1 4120005199003 小端盖YGDF-25-05 Cover Y 2

2 4120007617001 O形圈31.5×2.65 GB3452.1-82 O-ring Y 2

3 4120005199002 动臂阀杆YGDF-32-03b Spool N 1

4 4120005199025 测压口堵头GDF-32-18 Plug Y 1

5 4120007617002 O形圈11.8×2.1 GB3452.1-82 O-ring Y 1

6 4120007617003 O形圈20×2.4 GB1235-76 O-ring Y 1

7 4120001054222 螺塞D32-3 Plug Y 1

8 4120007617004 O形圈50×3.1 GB1235-76 O-ring Y 1

9 4120007617005 O形圈32×3.1 GB1235-76 O-ring Y 1

10 4120005199028 螺塞DF-32-20A Plug Y 1

11 4120003809004 阀体YGDF-32-01B1 Valve body Y 1

12 4120005199024 弹簧座YGDF-32-04 Spring seat N 1

13 4120001054215 弹簧D32-7 Spring Y 2

14 4120005199012 弹簧YGDF-25-09 Spring N 2

15 4120005199014 弹簧座YGDF-25-11 Spring seat N 3

16 4120005199015 阀杆接头D32-21 Joint Y 2

17 4120005199023 端盖YGDF-25-03 Cover Y 1

18 4120007617006 O形圈54.5×2.65 GB3452.1-82 O-ring Y 1

19 4120005199022 活塞YGDF-32-05 Piston N 1

20 4120007617007 O形圈46.2×3.55 GB3452.1-82 O-ring Y 1

21 4120005199021 复位弹簧YGDF-25-10 Spring N 1

22 4120005199020 压盖YGDF-25-06 Plate N 1

23 4120007617008 圆柱头内六角螺钉M8×140 GB70-85 Screw Y 4

24 4120007617009 圆柱头内六角螺钉M8×100 GB70-85 Screw Y 4

25 4120005199011 端盖YGDF-32-12 Cover Y 1

26 4120007617010 O形圈55×3.1 GB1235-76 O-ring Y 2

27 4120007617011 螺栓M12×20 GB30-76 Screw Y 2

28 4120007617012 垫圈12 GB97.1-85 Washer Y 2

29 4120007618002 安全阀XDY32G02-00A-18.5 Valve Y 1

30 4120002304002 高压过载阀D32A.1-00b（20MPa） Pressure limiting valve Y 1

31 4120007617013 O形圈28×3.1 GB1235-76 O-ring Y 2

32 4120002432430 过载阀阀体ZL50106C1-01A Valve Y 1

33 4120007617014 O形圈32×3.1 GB1235-76 O-ring N 2

34 4120007617015 螺栓M10×60 GB5782-86 Screw Y 8

35 4120007617016 垫圈10 GB93-76 Washer Y 8

36 4120002432431 过载补油阀阀体 ZL50106C1-01 Valve Y 1

37 4120002038161 低压过载阀XDYB20G01-00E-12 Valve Y 1

38 4120005199009 单向阀GDF-32-08 Direction valve Y 2

39 4120005199008 单向阀弹簧GDF-32-07 Valve spring N 2

40 4120007617017 O形圈31.5×3.55 GB3452.1-82 O-ring Y 2

41 4120005199007 阀盖GDF-32-05 Valve cover N 2

42 4120003809005 转斗阀杆YGDF-32-06b Valve rod Y 1

43 4015000036 垫圈GB93-8-65Mn Spring washer Y 16

44 4120007617018 圆柱头内六角螺钉M8×65 GB70-85 Screw Y 8
