L938F AL20H-1前驱动桥总成 Front axle E0710-2907002502

1 29070024991 轮边减速器 Hub reduction N 2
2 29070024161 轮辋螺母M18 Nut Y 20
3 29070019782 半轴 Shaft half Y 2
4 29070019772 桥壳总成 Axle casing Y 1
5 29070019762 主传动总成 Final drive Y 1
6 4011001430 螺栓GB5786-M121.2535flZnyc-10.9- Bolt Y 14
7 29070015981 垫圈 Washer Y 14
8 4016000124 销GB119.2-10u830 Pin Y 2 9 29070023071 透气嘴 Breather cap Y 1 10 4013000425 螺母GB6173-M101flZnyc-05-480 Nut Y 1
11 29070019791 前桥标牌 Name plate N 1
12 4019000012 铆钉GB827-35-BL2 Rivet Y 4 13 29070021631 螺栓 Screw Y 8 14 29070011121 垫圈 Washer Y 8 15 4120002669 制动钳 Disc brake Y 2 16 4120001740 放气嘴 Nipple Y 2 17 29070014671 防护板 Protecting plate Y 2 18 4011001247 螺栓GB5783-M820flZnyc-8.8-480 Screw Y 4
19 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 4
20 29070021441 磁性螺塞 Plug Y 2
