L938F 散热泵总成 Hydraulic pump A0362-4120005967

1 4120005082201 前盖163A002T Cover N 1
2 4120005967201 后盖163B238T Cover N 1
3 4120005967202 主齿163F233T Drive shaft N 1
4 4120005082207 二级从齿163G018T Shaft N 1
5 4120005082209 侧板163J002T Side board N 2
6 4120005082210 孔用弹性挡圈565C-00016 Retaining ring N 1
7 4120005082211 外置轴承W58-48 Beaing N 1
8 4120005082212 油封W62-26-10 Sealing ring N 1
9 4120005082213 滑动轴承002B005T Plain bearing N 4
10 4120005082214 堵油螺钉S-0280 Screw N 1
11 4120005082215 圆柱销008A0006 Pin N 2
12 4120005082216 O型密封圈001E0006 O-ring N 1
13 4120005082217 E型密封圈006E003T Sealing ring N 2
14 4120005082218 E型挡圈007E002T Retaining ring N 2
15 4120005967203 螺栓001A0004 Screw N 4
16 4120005082221 垫圈W033-2 Washer N 4
17 4120005082222 密封件包 Sealing ring kit N 1
