L938F 多路阀(331001) Control valve assembly F1202-4120001054

1 4120001054004 端盖D32-1 Cover N 3

2 4120001054005 动臂阀杆D32-2 Spool N 1

3 4120001054006 阀体D32-4 Valve body N 1

4 4030000608 PO形圈GB1235-60*3.1 O-ring Y 3

5 4120001054007 弹簧D32-8 Spring Y 3

6 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 3

7 4011000087 螺栓GB5783-M12*20EpZn-8.8 Screw Y 3

8 4120001054009 端盖D32-5 Cover N 3

9 4120001054010 弹簧D32-7 Spring Y 3

10 4015000025 垫圈GB93-10-65Mn Spring washer Y 12

11 4014000217 螺钉GB70.1-M10*100EpZn-8.8 Screw Y 6

12 4120001054012 弹簧座D32-6 Spring seat N 6

13 7200000446 O型圈 O-ring Y 2

14 4120001054014 补油阀盖D32-13 Cover N 1

15 4120001054015 弹簧D32-14 Spring Y 1

16 4120001054016 补油阀D32-15 Valve Y 1

17 4120001054017 螺塞D32A-10 Plug N 3

18 4120001054018 O形圈8.9*2.3 O-ring Y 3

19 7200001075 O形圈50*3.1 O-ring Y 4

20 4120001054020 辅助阀杆D32A-11 Spool N 1

21 4030000706 O形圈GB1235-44*3.5 O-ring Y 4

22 4120001054022 阀盖D32-19 Valve cover N 4

23 4120001054023 弹簧D32-16 Spring Y 4

24 4120001054024 单向阀D32-17 Check valve N 4

25 4030000707 O形圈GB1235-55*3.1 O-ring Y 1

26 4120001054026 转斗阀杆D32-12 Valve rod N 1

27 4014000115 螺钉GB70.1-M10*1.5*45EpZn-8.8 Screw Y 6

28 4120001054003 小腔过载补油阀 Valve Y 1

29 4120001054002 大腔过载补油阀 Check valve Y 1

30 4120001054029 堵头D32A-20 Plug N 1

31 4030000149 O形圈GB1235-35*3.5 O-ring Y 1

32 4120001054030 螺栓D32A-21 Screw N 5

33 4120002303001 安全阀D32.2a-00 Relief valve Y 1

34 4120001054031 阀体D32A-22 Valve body N 1

35 4120001054032 堵头D32A-23 Plug N 2

36 4120001054033 阀杆接头D32-21 Joint N 3

37 4120001054034 调整垫片D32-9 Shim N 1

38 4120002303004 螺塞D32-3 Plug Y 3

39 4030000011 O形圈GB1235-20*2.4 O-ring Y 3
