L956F A515C摆动型驱动桥总成 Rear axle assembly E0910-2909001331

1 29090013321 A515C后驱动桥总成 Rear axle Y 1

2 29090100051 前摆动支架 Bracket Y 1

3 29090000051 套 Sleeve Y 1

4 4011001323 螺栓GB5785-M16*1.5*50flZnyc-8.8-480 Screw Y 24

5 29070009511 垫圈 Washer Y 24

6 29090000062 衬套 Sleeve Y 1

7 29090100061 后摆动支架 Bracket Y 1

8 4041000021 O形圈LGB308-260*3.5 O-ring Y 1

9 29090009551 支承轴 Support shaft Y 1

10 4011001243 螺栓GB5783-M12*35flZnyc-8.8-480 Screw Y 6

11 29070010131 垫圈 Washer Y 12

12 29090000101 密封盖 Sealing cover Y 1

13 4030000021 O形圈GB3452.1-160*5.30G O-ring Y 1

14 29090000141 端盖 End plate Y 1

15 4011001367 螺栓GB5785-M20*1.5*90flZnyc-8.8-480 Bolt Y 4

16 29070011121 垫圈 Washer Y 4

17 29090000131 垫块 Block Y 1

18 29090000121 衬垫 Shim Y 2

19 4011001317 螺栓GB5782-M12*50flZnyc-8.8-480 Screw Y 6

20 29090000161 垫片 Shim Y 1

21 29090000112 轴套 Sleeve Y 1
