L956F 离合器K12 Clutch C0520-2905002519

1 29050014381 K12 轴 Clutch shaft Y 1

2 29050013911 活塞环 Piston ring Y 3

3 4021000161 轴承25590/25520/Q Bearing Y 1

4 29050014321 定位环 Locating ring Y 1

5 4110000628 轴承NTA-3446 Bearing Y 4

6 4110000625 轴承WJ-344016 Bearing Y 2

7 29050024001 齿轮总成R31 Gear Y 1

8 29050014611 隔套 Spacer sleeve Y 1

9 29050013951 隔离环 Spacer ring Y 2

10 29050013961 离合器轮毂 Clutch hub Y 1

11 29050013981 弹簧 Spring Y 1

12 29050014591 活塞 Piston Y 1

13 29050014581 隔离架 Separator Y 1

14 29050014571 活塞环 Piston ring Y 2

15 29050014141 离合器轮毂 Clutch hub Y 1

16 29050014531 活塞 Piston Y 1

17 29050014121 弹簧 Spring Y 1

18 29050013871 从动摩擦片 Friction disc Y 10

19 29050013861 主动摩擦片 Friction disc Y 16

20 29050015511 从动摩擦片 Friction disc Y 6

21 29050013851 受压盘 Pressure disc Y 2

22 29050014431 齿轮总成R32 Gear Y 1

23 29050013841 卡环 Retaining ring Y 2

24 29050013831 卡环 Retaining ring Y 2

25 29050014041 止推垫片 Shim Y 4

26 29050013811 止推垫片 Shim Y 1

27 29050014061 挡圈54 Retaining ring Y 1

28 4021000162 轴承33209/Q Bearing Y 1

29 4030000821 O形圈GB3452.1-77.5*3.55G-FPM O-ring Y 1

30 29050013491 调整垫片 Shim Y 6

31 29050013481 调整垫片 Shim Y 4

32 29050013471 调整垫片 Shim Y 2

33 29050013461 轴承保持架 Bearing seat Y 1

34 29050013451 垫片 Shim Y 6

35 4014000171 螺钉GB70.1-M8*25-8.8 Screw Y 6

36 4030000595 油封58*72*8 Sealing ring Y 1

37 4110000626 轴承WJ-344024 Bearing Y 1

38 29050013931 止推垫片 Shim Y 2

39 29050013971 活塞环 Piston ring Y 2

40 29050013991 卡环 Retaining ring Y 2

41 29050014561 活塞环 Piston ring Y 2

42 4090000130 钢球GB308-8.5-GCr15 Ball Y 2

43 29050026131 调整垫片 Shim Y 1
